Full Neutral, Reduced Neutral 1/3 Neutral, Mv Concentric Cable

YIFANG ELECTRIC GROUP INC.
  • Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication
  • Voltage：Low and Medium Voltage Cable
  • Current：DC & AC
  • Insulation Material：XLPE,PVC,PE
  • Sheath Material：PVC or LDPE or LLDPE
  • Material Shape：Round Wire

Base Info

  • Model NO.：Concentric cable-B-90
  • Wire Core Material：Copper or Aluminum
  • Certification：ISO, CCC, CE, RoHS, UL, VDE
  • Model：Concentric Cable
  • Brand：Yifang
  • Core：1+1,2+1,3+1
  • Sheath Colour：Black , Other as Per Requirement
  • Transport Package：Roll,Wooden Drum,Iron Wooden Drum,Steel Drum
  • Specification：25-1000mm2
  • Trademark：Yifang Cable
  • Origin：Zhengzhou, Henan, China
  • HS Code：8544921000
  • Production Capacity：500km Per Month

Description

Basic Info.

Model NO. Concentric cable-B-90 Wire Core Material Copper or Aluminum Certification ISO, CCC, CE, RoHS, UL, VDE Model Concentric Cable Brand Yifang Core 1+1,2+1,3+1 Sheath Colour Black , Other as Per Requirement Transport Package Roll/Wooden Drum/Iron Wooden Drum/Steel Drum Specification 25-1000mm2 Trademark Yifang Cable Origin Zhengzhou, Henan, China HS Code 8544921000 Production Capacity 500km Per Month

Product Description

Full neutral, Reduced Neutral 1/3 Neutral, MV Concentric Cable

1. The cable belongs to XLPE Insulated single core, concentric neutral cables rated 5 to 45KV which are used for the transmission and electrical energy, distribution of electrical energy.

2. Reference Standard: ICEA S-94-649, CSA C68.5, IEC60502.

3. Cable construction

3.1 Conductor: Stranded Compacted Copper or Aluminium Wire, Class B
3.2 Conductor shield: Semi-conductor XLPE Compound
3.3 Insulation: XLPE or TRXLPE
3.4 Insulation shield: Semi-conductor XLPE Compound
3.5 Concentric neutral wire: Round Annealed Copper Wire, Full neutral or Reduced neutral
3.6 Wrapping tape(optional): Non-woven clothing tape
3.7 Outer sheath: PVC/LDPE/LLDPE/HDPE

4. Packing: Roll/Wooden drum/Iron-wooden drum/ Steel drum

For further information, pls contact us directly.
