• Model：RG6,U
• Brand：Feiya
• Model Number：2,3 ,4 ,5 Cores, etc.
• OEM：Yes
• ODM：Yes
• Colors：Assorted Upon Request
• Operating Environment：High Frequency Transmission
• Transport Package：Submersible Pump, Heavy Duty ,Colliery
• Trademark：Fengda
• Origin：Tianjin, China
• HS Code：8544421900

Basic Info.

Model RG6/U Brand Feiya Model Number 2/3 /4 /5 Cores, etc. OEM Yes ODM Yes Colors Assorted Upon Request Operating Environment High Frequency Transmission Transport Package Submersible Pump/ Heavy Duty /Colliery Trademark Fengda Origin Tianjin, China HS Code 8544421900

Product Description

Features:

• The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers
• H-outer sheath = halogen-free material (HM2)
• RG-Coaxial types are in accordance with US-Military specifications MIL-C-17.
• RG/U: R=Radio, G=Guide, U=Utility
• FRNC = Flame Retardant Non-Corrosive

Application:
Coaxial cables are used in high frequency transmission, especially for transmitters and receivers, computers, radio and TV transmissions. The varied mechanical, thermal and electronic properties of Coaxial cables mean that they can be used up into the GHz levels, as per cable type.

 Coaxial cables

Inner conductor diameter mm	7 x 0,4 Tinned copper	19 x 0,2 Tinned copper	1 x 0,6 Steel/copper, bare	1 x 0,6 Steel/copper, bare	1 x 0,6 Steel/copper, bare	7 x 0,8 Copper, bare	7 x 0,8 Silvered copper
Insulation Ø mm	7,3   PE	2,95   PE	3,7   PE	3,7   PE,hollow	3,7   PE,hollow	7,24   E	7,24   PE
Outer conductor	Braid	Braid	Braid	Braid	2 braids	Braid	2 braids
	Copper, bare	Tinned copper	Copper, bare	Copper, bare	Copper, bare,Tinned copper	Copper,bare	2xsilvered copper
Outer sheath	HM2	HM2	HM2	HM2	HM2	HM2	HM2
Min. bending radius approx. mm	50	25	30	30	30	50	50
Temperature range °C	35 to +80	35 to +80	-35 to +80	35 to +80	50 to +70	35 to +80	-35 to +80
Copper weight kg/km	58,0	29,0	28,0	28,0	48,0	85,0	120,0
Outer Ø approx. mm	10,3	5,4	6,4	6,4	6,9	10,3	10,8
Weight approx. kg / km	144	38	57	54	64	155	203



FAQ

Q1: Are you a trading company or manufacturer?

A1: Tianjin Feiya wire & Cable Co., Ltd. is a professional manufacturer.

Q2: What kinds of products does Tianjin Feiya wire & Cable Co., Ltd. Manufacture?

A2: Our products mainly cover low, medium and high voltage (KV) crosslinked polyethylene insulated power cable, PVC insulated power cable, PVC insulated wire (construction cable), control cable, signal cable, rubber cable, coal mine cable, welding cable, ship cable and other related customized cables. These cables are used in Power metallurgy, Oil&Chemical Industry, Nation Defense Power Station, Mine, Port and Architectural Engineering, andother fields.

Q3: Which standards do you comply with when you produce the electrical wires and cables?

A3: We have passed ISO9001: 2000 and ISO140001: 2004. All products conform to GB, IEC, BS, ASTM, VDE JB and UL standards. Besides, we have the ability to design and produce various wires and cables, and customize them for you according to the special requirements of customers (providing OEM services).

Q4: What is your MOQ?
A4: It`s base on the cable type or wire type. Please contact Calder. He will let you know.

Q5: How much the Courier freight will be for the samples?

A5: Courier freight depends on the quantity, weight and carton size and your area.
