• Model NO.：Natura color Armored F,UTP CAT6A Patch Lead
• Wire Core Material：Bare Copper Wire
• Certification：CE, ISO, RoHS
• Model：S,FTP CAT6A
• Brand：Hanli
• Test：Pass Fluke Test
• Standard：Eia,Tia 568b or 568A
• Operating Temperature：-40ºC~+70ºC
• Transmit Rate：500MHz
• Performance Feature：Anti-Crush and Rodent-Proof
• Transport Package：as Customer Require
• Specification：0.5m, 1m, 1.5m, 3m, 5m, 10m, 15m, 20m
• Trademark：Hanli
• Origin：China
• HS Code：8544421900
• Production Capacity：50000PCS,Month

Basic Info.

Model NO. Natura color Armored F/UTP CAT6A Patch Lead Wire Core Material Bare Copper Wire Certification CE, ISO, RoHS Model S/FTP CAT6A Brand Hanli Test Pass Fluke Test Standard Eia/Tia 568b or 568A Operating Temperature -40ºC~+70ºC Transmit Rate 500MHz Performance Feature Anti-Crush and Rodent-Proof Transport Package as Customer Require Specification 0.5m, 1m, 1.5m, 3m, 5m, 10m, 15m, 20m Trademark Hanli Origin China HS Code 8544421900 Production Capacity 50000PCS/Month

Product Description

32AWG Natura color Armored F/UTP CAT6A Patch Lead
1,32AWG /26AWG  F/UTP
 2,19 years factory
 3, 25 years quality assurance
 4,CE,ROHS,ISO9001 certificates

Specifications:
         Conductor: 1x32AWG stranded copper / CCA or Bare Solid copper / CCA
         Patch cord plug: RJ-45 plug 8P8C
         Boot:: FR PVC high-injection
         Insulatiion: HDPE
         Jacket : PVC,PE or LSZH
         Nominal OD: 3.8+/-0.2mm
         Color codes:
                                   Pair  1 :  white / blue and blue
                                   Pair  2 :  white / orange and orange
                                   Pair  3 :   white / green and green
                                   Pair  4 :   white /  brown and brown
         Lengths: 0.5M,1M,2M,3M,5M,10M,15M,20M (special lengths are accepted)
         Lan cable standard compliance category:6 A TIA/EIA-568-B-2.1 or ISO / IEC 11801

Applications:
  * Improved attenuation provides cleaner data and video transmissions
   * For 1000Base-T,100Base-TX,500Mbps ATM and other high-speed applications
   * Designed for Lan network system and computer networks
   * Distributing system,telecommunications  network system,testing equipment  system and CATV system

Features:
  * Fast  and convenient connection
   * Perfect combination of high quality Cat6a cable and RJ45 connector
   * Insures excellent reliability and stability

 Kuayue patch leads provide a high quality, high performance solution for all your network patch lead requirements.
If you are looking for something a bit nicer than our standard patch leads then these are the deal.
Kuayue patch leads are manufactured to the highest standards in an ISO9001 certified factory.
Only top quality components are used ensuring long term reliability and compatibility.

Note: steel tape color is optional.
          Nicket plated connector or gold plated connector is optional.
Welcome to visit our factory and  get our samples.

  Your inquiry will be answered within 24 hours .Wishing to be your long- term partner ,please feel free to contact me ,we will do our best for you.

  Choose us, won't make you disappointed:
1.18 years manufactory experience
2.OEM/ODM available
3.Steady product quality
4.Strict quality control
5.Strictly conform to CE,ROHS,Iso9001&ISO14001 certificate
6.Quick delivery time(20ft,25days)
