• Model NO.：YVVB YFFB YEEB YGGB YVFB
• Material Shape：Flat Wire
• Range of Application：Mobile
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE
• Brand：Feiya
• OEM：Yes
• Transport Package：Wooden Box Packing or Pallet Shipping Containers
• Specification：copper
• Trademark：Feiya
• Origin：China
• HS Code：854449210
• Production Capacity：50K Meter Per Year

Basic Info.

Model NO. YVVB YFFB YEEB YGGB YVFB Material Shape Flat Wire Range of Application Mobile Certification ISO9001, CE, UL, CCC, RoHS, VDE Brand Feiya OEM Yes Transport Package Wooden Box Packing or Pallet Shipping Containers Specification copper Trademark Feiya Origin China HS Code 854449210 Production Capacity 50K Meter Per Year

Product Description

Movable Type Flat Cable




























 Movable Type Flat Cable
Application

It is used as sighal transmission wire of applianles, meters and automatie control system in petroleum, chemisty power gmernting and metallurgy. Type and Designation


Type	Designation
YVVB	Soft PVC insulation & sheathed mobile flat cable
YFFB	Nitrile-Butadiene Rubber  insulation & shethed mobile flat cable
YEEB	Thermoplastic insulation & sheathed mobile flat cable
YGGB	Silica rubber insulated & sheathed mobile flat cable
YVFB	PVC insulated thermoplastic sheath mobile flat cable

Use characteristics and technical performance

1.The rated voltage U₀/U 0.6/1kV

2.Cable conductor long-term working temperature :PVC insulated, nitrile PVC insuated, thermoplastic elastic body insulaton does not exceed 70ºC;Silicone rubber isnualtion does not exceed 180ºC

3.The minmum bending radius shoule not less than 6 times of cable diameter

4.Cable lowest runtime environment temperature:PVC insulated is not lower than 0ºC;Nitrile PVC composite insulation, thermoplastic projectile insulation not below -20ºC;Silicone rubber insulation not bellow to -40ºC

5.20ºC conducror DC resistance in accordance with the provisions of the GB/T 3956-2008.

6.Power frequency voltage test:3.5kV/5min cable breakdown.


FAQ

Q1:Are you a trading company or manufacturer?

A1: Tianjin Feiya wire & Cable CO., LTD. is a professional manufacturer.

Q2: What kinds of products does Tianjin Feiya wire & Cable CO., LTD. manufacture?

A2: Our products mainly cover low, medium and high voltage (KV) crosslinked polyethylene insulated power cable,PVC insulated power cable, PVC insulated wire (construction cable), control cable, signal cable, rubber cable,coal mine cable, welding cable, ship cable and other related customized cables. These cables are used in Power metallurgy, Oil&Chemical Industry, Nation Defense Power Station, Mine, Port and Architectural Engineering, andother fields.

Q3:Which standards do you comply with when you produce the electrical wires and cables ?

A3: We have passed ISO9001:2000 and ISO140001:2004. All products conform to GB, IEC, BS, ASTM, VDE JB and UL standards. Besides, we have the ability to design and produce various wires and cables, and customize them for you according to the special requirements of customers (providing OEM services).

Q4: What is your MOQ?
A4: It`s base on the cable type or wire type. Please contact Calder. He will let you know.

Q5:How much the Courier freight will be for the samples?

A5:Courier freight depends on the quantity,weight and carton size and your area.
