Cable & Wire

Heat-Resistant Flame-Retardant Stranded Copper PVC Insulated Electrical Wire 16mm 35mm

Henan Hongda Cable Co., Ltd.
  • Type:Insulated
  • Conductor Type:Stranded
  • Application:Overhead, Underground
  • Conductor Material:Copper
  • Sheath Material:PVC
  • Insulation Material:Bare

Base Info

  • Model NO.:BVR BV
  • Material Shape:Round Wire
  • Range of Application:Flame Retardant
  • Certification:ISO9001, CCC
  • Class of Conductor:5 or 2
  • Rated Voltage:450,750 V
  • Manufacture Standard:IEC 60227
  • Transport Package:100m Per Roll, 100FT Per Roll
  • Specification:0.75mm to 2.5mm2
  • Trademark:Hongda Twisted cable
  • Origin:China
  • HS Code:8544492900
  • Production Capacity:40km,Day

Description

Basic Info.

Model NO. BVR BV Material Shape Round Wire Range of Application Flame Retardant Certification ISO9001, CCC Class of Conductor 5 or 2 Rated Voltage 450/750 V Manufacture Standard IEC 60227 Transport Package 100m Per Roll, 100FT Per Roll Specification 0.75mm to 2.5mm2 Trademark Hongda Twisted cable Origin China HS Code 8544492900 Production Capacity 40km/Day

Product Description

 Heat-Resistant Flame-Retardant stranded copper PVC insulated  electrical wire 16mm 35mm

Heat-Resistant Flame-Retardant Stranded Copper PVC Insulated Electrical Wire 16mm 35mm
Heat-Resistant Flame-Retardant Stranded Copper PVC Insulated Electrical Wire 16mm 35mm
Heat-Resistant Flame-Retardant Stranded Copper PVC Insulated Electrical Wire 16mm 35mm


Specifications

1.Certificate: SGS,ISO,CCC
2.Standard: IEC60227
3.High quality

Applications:
The product is fit for ac rated voltage 450/750 and below of domestic electrical applicances of smaller size motoriace tools of instruments of varous meters and motorized lighting installations.
This prduct is suitable to be used in household appliances ,electric tools and lighting in home , office and similar indoor place where request flexible wire

Technological property:
1)If finished insulation core and finished power line is pot into warm water20+/-5 °c for an hour, they will be able to bear stipulated as soaked, soaked voltage test as stated in table.
2)Wire has excellent electric insulation property, mechanical property, non-inflammability. So it is safety and convenience in using the producters name. The model and the voltage should be cleany printed on the surface of the finished power line of insulation and sheath delivery requirements.
Nominal
Area

Insulated
Thickness

Sheathed
Thickness

Approx.
dia of cable

Cable approx weight
D.C
Resisance
Of conductor
20°C(Ω/km)

Least
Insulates
resistance
mm²mmmmmm(kg/km)(Ω/km)mΩ/km
2×0.750.60.86.650.839.00.011
2×1.00.60.87.059.219.50.010
2×1.50.70.8878.613.30.010
2×2.50.71.09.4114.17.980.009

Heat-Resistant Flame-Retardant Stranded Copper PVC Insulated Electrical Wire 16mm 35mm

*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Any needs or question, please contact me Mobile:+86-13783451632 , we will be more pleasure to service you.
We are looking forward to your inquiry and nice cooperation.
Heat-Resistant Flame-Retardant Stranded Copper PVC Insulated Electrical Wire 16mm 35mm
