New Energy DC Solar Power Cable H1z2z2-K /PV1-F Twin Solar Cable 4mm, 6mm Solar PV Cable

Tianjin Feiya Electric Wire & Cable Co., Ltd.
  • Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer
  • Voltage：Low and Medium Voltage Cable
  • Current：DC & AC
  • Insulation Material：XLPE, PVC, PE, Rubber and etc.
  • Sheath Material：XLPE, PVC etc. Cable
  • Material Shape：Round Wire

Base Info

  • Wire Core Material：Red Copper Wire
  • Certification：ISO, CCC, CE
  • Model：Wdz-Yjly
  • Brand：Fengda
  • Transport Package：Export Drum
  • Trademark：fengda
  • Origin：Tianjin, China

Description

Size

 Cross Section

 Conductor Structure

 Outer Diameter

 Max. DC Resistance at 20ºC

Rated Voltage

Rated Current

 mm² mm mm Ω/km V DCA 2 x 2.5mm² 2.5mm² 49 x ∅0.25 5.4 X 10.9 8.061000/150030A 2 x 4.0mm² 4.0mm² 56 x ∅0.285 6.1 X 12.3 4.97 1000/150050A 2 x 6.0mm² 6.0mm² 78 x ∅0.30 6.4 X 12.9 3.52 1000/150070A





Advantage:

·Dual wall insulation.Electron beam cross-linked

·Excellent resistance to U.V,oil,greases,oxygen and ozone

·Excellent resistance to abrasion

·Halogen free, flame retardant,low toxicity

·Excellent flexibility and stripping performance

·High Voltage and Current carring capacity

·TUV,CE approved
