N2xsy/Na2xsy Electric Single Core XLPE Insulated Copper Wire Shield 11kv Aluminum Power Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground, Building Wire
- Conductor Material：Copper
- Sheath Material：PE
- Insulation Material：XLPE
Base Info
- Model NO.：N2XSY
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, CCC, RoHS, VDE
- Brand：Fengda
- Colour：Red,Green,Blue,Black,White,as Request
- Flame Test：Yes
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Factory Type：Manufacturer
- Transport Package：Rolls or According to Cusotmers′ Reques
- Specification：0.12 to 400mm2
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：5000000km,Year
Description
Application
These cables are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz., they are suitable for use in distribution installation, electrical power station , they are applied for installation, outdoors, underground where subject to mechanical damage.
Standard
AS/NZS 1429.1
Cable Construction
- CONDUCTOR: Plain circular compacted copper to AS/NZS1125 Maximum Continuous Operating Temperature: 90°C
- CONDUCTOR SCREEN: Extruded semi-conducting compound, bonded to the insulation and applied in the same operation as the insulation
- INSULATION: Cross Linked Polyethylene (XLPE) - standard Ethylene Propylene Rubber (EPR) - alternative
- INSULATION SCREEN: Extruded semi-conducting compound
- METALLIC SCREEN: Plain annealed copper wire: 10kA for nominal 1 second(HEAVY DUTY)
- BEDDING: PVC
- ARMOURING: Galvanised steel wires
- SHEATH: Black 5V-90 polyvinyl chloride (PVC) - standard
- Orange 5V-90 PVC inner plus black high density polyethylene (HDPE) outer - alternative Low smoke zero halogen (LSOH) - alternative
Technical Characteristics
| NOMINAL COND UCTOR AREA | MAXIMUM CONDUCTOR DC RESISTANCE AT 20°C | COND. AC RESISTANCE AT 50HZ AND 90°C | INDUCTIVE REACTANCE AT 50HZ | INSUL ATION RESIS TANCE AT 20°C | CONDUCTOR TO SCREEN CAPACI TANCE | CHARGING CURRENT PER PHASE | DIEL ECTRIC LOSS PER PHRASE | MAXIMUM DIAELECTRIC STRESS | SCREEN DC RESIST ANCE AT 20°C | ARMOUR DC RESISTA NCE AT 20°C | ZERO SEQUE NCE RESIST ANCE AT 20°C | ZERO SEQ. REACT. AT 50HZ |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MM2 | OHM /KM | OHM /KM | OHM /KM | MEGOHM. KM | ΜF X KM | A X KM | W X KM | KV X MM | OHM /KM | OHM /KM | OHM/KM | OHM/KM |
| 16 | 1.15 | 1.47 | 0.134 | 11000 | 0.221 | 0.263 | 4 | 2.06 | 1.06 | 0.857 | 2.58 | 0.0842 |
| 25 | 0.727 | 0.927 | 0.127 | 9700 | 0.248 | 0.296 | 4.5 | 1.99 | 0.706 | 0.811 | 1.86 | 0.077 |
| 35 | 0.524 | 0.668 | 0.12 | 8700 | 0.276 | 0.33 | 5.01 | 1.93 | 0.533 | 0.657 | 1.41 | 0.0712 |
| 50 | 0.387 | 0.494 | 0.115 | 7800 | 0.308 | 0.368 | 5.59 | 1.87 | 0.366 | 0.616 | 1.08 | 0.066 |
| 70 | 0.268 | 0.342 | 0.109 | 6900 | 0.352 | 0.42 | 6.39 | 1.82 | 0.265 | 0.559 | 0.807 | 0.0603 |
| 95 | 0.193 | 0.247 | 0.101 | 6000 | 0.404 | 0.482 | 7.33 | 1.77 | 0.265 | 0.521 | 0.721 | 0.0525 |
| 120 | 0.153 | 0.196 | 0.0969 | 5400 | 0.447 | 0.534 | 8.11 | 1.74 | 0.266 | 0.487 | 0.669 | 0.0491 |
| 150 | 0.124 | 0.16 | 0.0942 | 5000 | 0.486 | 0.58 | 8.81 | 1.72 | 0.265 | 0.458 | 0.629 | 0.0467 |
| 185 | 0.0991 | 0.128 | 0.0917 | 4600 | 0.53 | 0.632 | 9.61 | 1.69 | 0.265 | 0.431 | 0.593 | 0.0443 |
| 240 | 0.0754 | 0.0986 | 0.089 | 4200 | 0.576 | 0.687 | 10.4 | 1.61 | 0.266 | 0.307 | 0.504 | 0.0418 |
| 300 | 0.0601 | 0.0798 | 0.0879 | 4000 | 0.597 | 0.713 | 10.8 | 1.49 | 0.265 | 0.284 | 0.473 | 0.0409 |
| 400 | 0.047 | 0.064 | 0.0852 | 3800 | 0.627 | 0.749 | 11.4 | 1.38 | 0.265 | 0.257 | 0.44 | 0.0384 |
Cable Parameter
| SECTIONAL AREA OF CONDUCTOR | NOM. CONDUCTOR DIAMETER | NOM. INSULATION THICKNESS | NOM. DIAMETE OVER INSULATION | SCREEN AREA ON CORES | NO. AND DIAMTER OF SCREENED WIRES | NOM. DIAMETE OVER SCREENED WIRES | NOM. DIAMETE OVER BEDDING | NOM. DIAMETE OF ARMOUR | NOM. DIAMETE OVER ARMOUR | NOM. OVERALL DIAMETER | APPROX. MASS |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MM2 | MM | MM | MM | MM2 | NO X MM | MM | MM | MM | MM | MM | KG/100M |
| 16 | 4.8 | 2.5 | 11 | 17 | 10 x 0.85 | 14.3 | 34 | 2 | 38 | 42.6 | 295 |
| 25 | 5.8 | 2.5 | 12 | 25.5 | 15 x 0.85 | 15.3 | 36.1 | 2 | 40.1 | 44.9 | 345 |
| 35 | 6.8 | 2.5 | 13 | 34 | 20 x 0.85 | 16.3 | 38.5 | 2.5 | 43.5 | 48.7 | 440 |
| 50 | 8 | 2.5 | 14.1 | 49.4 | 29 x 0.85 | 17.4 | 41 | 2.5 | 46 | 51.4 | 515 |
| 70 | 9.6 | 2.5 | 15.7 | 68.1 | 40 x 0.85 | 19 | 44.6 | 2.5 | 49.6 | 55.2 | 630 |
| 95 | 11.5 | 2.5 | 17.6 | 68.1 | 40 x 0.85 | 20.9 | 48.9 | 2.5 | 53.9 | 59.7 | 745 |
| 120 | 13.1 | 2.5 | 19.2 | 68.1 | 40 x 0.85 | 22.5 | 52.3 | 2.5 | 57.3 | 63.3 | 850 |
| 150 | 14.5 | 2.5 | 20.6 | 68.1 | 40 x 0.85 | 23.9 | 55.7 | 2.5 | 60.7 | 66.9 | 960 |
| 185 | 16.1 | 2.5 | 22.2 | 68.1 | 40 x 0.85 | 25.5 | 59.4 | 2.5 | 64.4 | 70.8 | 1090 |
| 240 | 18.5 | 2.6 | 24.9 | 68.1 | 40 x 0.85 | 28.2 | 65.3 | 3.15 | 71.6 | 78.6 | 1410 |
| 300 | 20.7 | 2.8 | 27.6 | 68.1 | 40 x 0.85 | 30.9 | 71.4 | 3.15 | 77.7 | 85.2 | 1660 |
| 400 | 23.6 | 3 | 30.9 | 68.1 | 40 x 0.85 | 34.2 | 78.8 | 3.15 | 85.1 | 92.9 | 2030 |
