Jumper Wire Cable 1*2*0.5cu and Jumper Wire

Zhejiang Kuayue Cable Co., Ltd.
  • Application：Local Communication Cable, LAN Cable, Long Distance Symmetric Cable, Submarine Cable
  • Conductor Material：BC,CCS,CCA,TC,CU,CCAG
  • Cover Material：PE
  • Type：Jumper Wire Cable
  • Material Shape：Hollow Line
  • Conductor Type：Solid

Base Info

  • Model NO.：jumper wire
  • Wire Core Material：Bare Copper Wire
  • Certification：CE, RoHS
  • Model：Jumper Wire Cable
  • Brand：Kuayue
  • Transport Package：500&1000m
  • Specification：20x20x20cm
  • Trademark：kuayue
  • Origin：Zhejiang

Description

ConductorInsulationMaterialNom. O.D. (mm)MaterialNom. O.D. (mm)Bare copper24AWG(0.5)HDPE0.9Polyvinyl Chloride(PVC)1.1
Electrical CharacteristicsITEMUnitsValue0.40.5Conductor resistance, maximum,Ω/km  (20ºC)14895Mutual pairs capacitancenF/km56Dielectric strength (DC test voltage for 1 min, )     DC (V)1000Insulation resistance, minimumM Ω /km5000ImpedanceΩ100±15Delays/km1MHz≤6.4 10MHz≤5.7
