Stranded Copper Braided Shielded 50 Ohm Rg213 CCTV Coaxial Cable
Hangzhou Spring Electronics Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, LAN Cable, Long Distance Symmetric Cable, Submarine Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：Cat 1
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：RG213
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS
- Model：MHYV-xx
- Brand：OEM
- Braiding：32,48,64,96,112,128,144
- Coaxial Cable Type：Rg213 Coaxial Cable
- Coaxial Cable Model：50ohm Coaxial Cable
- Conductor Size：7X0.75mm
- Transport Package：200m,300m,305m
- Specification：2.74mm Conductor
- Trademark：FUU
- Origin：China
- HS Code：8544200000
- Production Capacity：3500km,Month
Description
Overview
ConstructionItem Material Diameter(Inch/mm) Inner Conductor Stranded Bare Copper 7/0.029 7/0.75 Dielectric Solid PE 0.285 7.25 Out Conductor BC/CCA 97% Braid 0.321 8.15 Jacket PVC/LSZH 0.406 10.30 Electrical Characteristics Capacitance(pF/m) 101.0 Impedance(Ω) 50.0 Velocity of Propagation(%) 66.0 Conductor DCR(ohm/km) 5.6 Outer Shield DCR(ohm/km) 3.9 Max Operating Frequency(MHZ) 11000.0 Max Operating Voltage(VRMS) 3700.0 Operating Temperature(0C) -40 to +85 Application These kind of cables are serving for the data and wireless communication systems where higher sequences and lower attenuation required.
2) Professional Quotation --All prices will be quote according to customers' detailed
specifications & requirements.
3) OEM & ODM Service
4) Can print your own brand on the jacket printing with foot or meter marking.
5) Make customized designs for stickers, drums, outer cartons, etc.
6) Stable Quality --All materials and products passed restrict QC procedures,comply with
international standards.
7) Fast Delivery --LCL orders,15days after confirmation; FCL orders, 20 days after
Confirmation in usual.
