• Model NO.：KVV KVV22
• Wire Core Material：Red Copper Wire
• Certification：ISO, CCC, CE, RoHS, UL
• Model：KVVP
• Brand：Yifang
• Core Number：2-61 Core
• Material：Copper + PVC + PVC
• Conductor Type：Stranded Conductor
• Color of Sheath：Black and Customer Designated.
• Transport Package：Drum or According to Customer′s Request
• Specification：0.5-25nn2
• Trademark：YIFANG
• Origin：China
• HS Code：8544492100
• Production Capacity：500km Per Week

Basic Info.

Model NO. KVV KVV22 Wire Core Material Red Copper Wire Certification ISO, CCC, CE, RoHS, UL Model KVVP Brand Yifang Core Number 2-61 Core Material Copper + PVC + PVC Conductor Type Stranded Conductor Color of Sheath Black and Customer Designated. Transport Package Drum or According to Customer′s Request Specification 0.5-25nn2 Trademark YIFANG Origin China HS Code 8544492100 Production Capacity 500km Per Week

Product Description

12x1.5mm2 pvc insulated shielded kvvr rvvp control cable for sale

Application: Suitable for the interconnection in controlling, protecting and measuring system.

Manufactured standards: GB/T9330 IEC60227 IEC60502

Production Scope:
Voltage 1KV or below
Conductor type: Flexible, Stranded or solid (class 1, 2, and 5)
Cross Section Area: 0.5mm2 to 10mm2
Core: from 2 to 61cores
Color of insulation: Red, yellow, yellow/green, white, black, grey, brown, orange etc.
Core's identification: by colour, Number or others as per customers request

Construction:
Conductor: IEC60228 class 2 and class 5 bear copper/Aluminum etc.
Insulation: PVC/XLPE/EPR
Shield (optional): Copper tape/Al-Mylar tape/Braiding
Armor (optional): Galvanized steel wire/ two layers of steel tape gap-wrapped
 / Galvanized steel interlocked armour/Aluminum alloy interlocked armour
Outer Sheath: PVC, PE, or other special requirements
