Flexible 450/750V 3X1.5mm2 Indoor Used Yc Heat Proof for DC Magnet Rubber Flexible Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground, Building Wire
- Conductor Material：Copper
- Sheath Material：Rubber
- Insulation Material：Rubber
Base Info
- Model NO.：YC
- Material Shape：Round Wire
- Range of Application：Wind Energy
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE, TUV
- Brand：Fengda
- Colour：Red,Green,Blue,Black,White,as Request
- Flame Test：Yes
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Factory Type：Manufacturer
- Transport Package：Rolls or According to Cusotmers′ Reques
- Specification：0.12 to 400mm2
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：5000000km,Year
Description
Model name of rubber cable
| HAR Code | IEC | Description | Voltage Design | Cores |
| H05RR-F | 60245 IEC 53(YZ)/YZ | Oridinary rubber sheathed flexibale rubber cable | 300/500V | 2~5 |
| H05RN-F | 60245 IEC 57(YZW)/YZW | Oridinary polychloroprene or other equivalent synthetic elastomer sheathed flexible rubber cable | 300/500V | 2~5 |
| H07RN-F | 60245 IEC 66(YCW)/YC | Heavy polychloroprene or other equivalent synthetic elastomer sheathed flexible cable | 450/750V | 1~5 |
Standard
GB5013-97
Application
This rubber insulated copper core welding cable is used for connecting the electrode to the welding machine. It has super flexibility and oil-resistant performance. It can also be used in other movable applications where high flexibility is required.
Specificatio
| Conductor | Copper |
| Type | YC/YCW |
| Rated Voltage | 450/750v |
| Color | Customized color |
| Package | Steel wooden drum |
| Jacket | Rubber |
| Insulation | Rubber |
