PVC Heating Cable Type 409 Composite Screened Power Cores 3X15 with a Single Extensible Pilot Open-Cut Mine Cable

Tianjin Feiya Electric Wire & Cable Co., Ltd.
  • Application：Underground, Industrial, Power Station
  • Voltage：Low and Medium Voltage Cable
  • Current：DC & AC
  • Insulation Material：Epr (R-Ep-90)
  • Sheath Material：Heavy Duty HD-85-Pcp
  • Material Shape：Round

Base Info

  • Model NO.：Type 409
  • Wire Core Material：Tinned Copper
  • Certification：ISO, CCC, CE
  • Model：Mc
  • Brand：Fengda
  • OEM / ODM：Available
  • Rated Voltage：1.1 Kv - 11 Kv
  • Installation Conditions：in Free Air, in Duct, Mobile Equipment, Machines
  • Behaviour in Flame and Fire：Fire Retardant
  • Transport Package：Drum
  • Specification：1.8m * 1.8m * 1.1m
  • Trademark：Fengda
  • Origin：China
  • HS Code：8544421900
  • Production Capacity：50000000 Meter , Year

Description

Basic Info.

Model NO. Type 409 Wire Core Material Tinned Copper Certification ISO, CCC, CE Model Mc Brand Fengda OEM / ODM Available Rated Voltage 1.1 Kv - 11 Kv Installation Conditions in Free Air, in Duct, Mobile Equipment, Machines Behaviour in Flame and Fire Fire Retardant Transport Package Drum Specification 1.8m * 1.8m * 1.1m Trademark Fengda Origin China HS Code 8544421900 Production Capacity 50000000 Meter / Year

Product Description

OPEN CUT MINE CABLES   1.1-11 kV
PVC Heating Cable Type 409 Composite Screened Power Cores 3X15 with a Single Extensible Pilot Open-Cut Mine Cable
Cable description
Class 2 composite screened cable with central pilot.

Application
Heavy duty trailing cable with good flexibility and high resistance to abrasion and weathering. Suitable for pumps, shovels,draglines, blasthole drill, etc. For improved performance, all cables (except 409.1 below 50 mm) incorporate a polyaramid yarn braid sheath reinforcement for exceptional tear and cut-through resistance. Cable designed for trailing and most reeling applications.

Temperature range:
Maximum operating temperature: +90 °C
Minimum operating temperature: -25 °C

Flexibility:Flexible

Resistance to
Chemical exposure: Very good/Frequent
Mechanical impact: Heavy
Water exposure: Immersion/Temporary coverage
Solar radiation and weather exposure: Suitable for direct exposure

Installation conditions
In free air / Mobile equipment
