Automotive Car Cable/Class Car Line
Jiangyin Yuanda Electrical Material Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Lighting System of Vehicle Engine
- Conductor Material：Copper
- Insulation Material：PVC
- Certification：Jaso D608
Base Info
- Color：Made to Order According to Customers′ Request
- Transport Package：Roll,Carton,Pallet,Tray
- Specification：From 1mm Diameter to 10mm
- Trademark：Yuanda
- Origin：Wuxi, China
- HS Code：8544492100
- Production Capacity：1000km,Day
Description
StyleConductor Insulation Dielectric strength
AC(V/30min) Nom. Area
mm² Num./Dia
(No./mm) Diameter
(mm) Min
thickness
(mm) Tolerance outer diameter
(mm) T2/T3 0.35 7/0.250 0.75 0.22 1.28~1.40 1000 0.6 12/0.250 1.00 0.28 1.76~1.90 1 19/0.250 1.25 0.3 1.99~2.15 1.4 27/0.250 1.50 0.32 2.25~2.40 2 37/0.250 1.75 0.36 2.62~2.80 3 45/0.300 2.41 0.4 3.25~3.45 4 56/0.300 2.59 0.4 3.70~3.90 5 70/0.300 3.29 0.4 3.80~4.00 7 105/0.300 4.03 0.48 4.76~5.00 10 144/0.300 4.76 0.48 5.75~6.00 16 126/0.400 5.88 0.52 6.75~7.00 20 150/0.400 6.50 0.52 7.25~7.50
AC(V/30min)
mm²
(No./mm)
(mm)
thickness
(mm)
(mm)
