• Model NO.：RG 6
• Brand：General Clad
• Center Conductor Material：Bare Copper
• Dielectric Material：Foam FEP
• Jacket Material：PVC
• Shield (Braid) Material：Tinned Copper
• Shield (Tape) Material：Aluminum,Poly
• Transport Package：Packed by Carton,Wooden Drum,Wooden Pallet
• Trademark：Copper clad steel wire
• Origin：China
• Production Capacity：200km,Month

Cable TypeSeries 6Center Conductor Type                                                    Solid Construction TypeNon-armoredJacket Color                                                                         White/BlackSupported Application Video
DimensionsCable Length304.8 m | 1000 ftDiameter Over Dielectric4.318 mm | 0.17 inDiameter Over Dielectric Tolerance±0.004 inDiameter Over Jacket Tolerance±0.004 inDiameter Over Jacket, nominal6.02 mm | 0.237 inDiameter Over Shield (Braid)5.207 mm | 0.205 inDiameter Over Shield (Tape)4.47 mm | 0.176 inJacket Thickness0.406 mm | 0.016 inJacket Thickness, minimum spot0.33 mm | 0.013 inCenter Conductor Gauge18 AWGShield (Braid) Gauge34 AWG
Electrical SpecificationsCapacitance52.493 pF/m | 16 pF/ftCharacteristic Impedance75 ohmCharacteristic Impedance Tolerance±3 ohmConductor dc Resistance6.4 ohms/kft | 20.997 ohms/kmDielectric Strength, conductor to shield2000 VdcJacket Spark Test Voltage4000 VacNominal Velocity of Propagation (NVP)84 %Shield dc Resistance3 ohms/kft | 9.843 ohms/kmStructural Return Loss20 dB @ 10-300 MHzStructural Return Loss Test Method100% Swept Tested
Material SpecificationsCenter Conductor MaterialBare copperDielectric MaterialFoam FEPJacket MaterialPVCShield (Braid) Coverage95 %Shield (Braid) MaterialTinned copperShield (Tape) MaterialAluminum/Poly
Package
