Outdoor Layer Stranded All Dielectric Cable GYFTY Cable
Hangzhou Softel Optic Co., Ltd.- Application：Fiber Optic Cable
- Conductor Material：Fiber
- Cover Material：PE
- Type：G652D
- Material Shape：Hollow Line
- Conductor Type：Stranded
Base Info
- Model NO.：GYFTY Cable
- Wire Core Material：Steel
- Certification：CE, ISO
- Model：GYFTY
- Brand：Softel
- Apply for：Directly Burial
- Fiber Count：2-432cores
- Cable Type：Sm or Mm
- Fiber Type：G652d
- Material of Jacket：MDPE,HDPE
- Fiber Optic Cable Tube：Central Loose Tube
- Model Name：Fiber Optic Cable
- Model No.：Gyty53
- Delivery Time：10 Days
- MOQ：2 Drum
- Transport Package：4km Wooden Drum
- Specification：size
- Trademark：SOFTEL
- Origin：China
- HS Code：85176229
- Production Capacity：1000km Per Month
Description
Fiber
count
Cable
dia.(mm) Cable net
weight(Kg/km) Min. bending
radius(mm) Min. tensile
strength(N) Min. crush
pressure(N/100mm) Static state Dynamic
state Short term Long term Short term Long
term 2-42 11.5 106 120 240 1500 600 1000 300 44-48 11.9 115 120 240 1500 600 1000 300 50-56 11.9 112 120 240 1500 600 1000 300 58-84 12.9 134 130 260 1500 600 1000 300 86-96 13.7 155 140 280 1500 600 1000 300 98-108 14.5 179 150 300 1500 600 1000 300 110-120 15.3 204 160 320 1600 600 1000 300 122-132 16.1 232 170 340 1800 600 1000 300 134-144 16.9 262 170 340 1900 600 1000 300
count
dia.(mm)
weight(Kg/km)
radius(mm)
strength(N)
pressure(N/100mm)
state
term
