• Model NO.：minicable
• Conductor Insulation：Fluoropolymer
• Outer Insulation：PVC
• Cold Lead：2-Wire Plus Ground Braid; 2.5m Length
• Transport Package：Innner Carton Master Carton
• Trademark：jiahong
• Origin：Anhui Wuhu
• Production Capacity：17000PCS Per Day

Cable Construction:Twin conductorRated Voltage:230VOutput:12W/m & 18W/mHeating Element Size:12.5-150.0m (12W/m) & 7.5-154.2m (18W/m)Bending radius:25 mmCable Diameter:3.6mmConductor Insulation:FluoropolymerOuter Insulation:PVCMax. Ambient Temp.:85ºF(30ºC)Min. Installation Temp.:40ºF(5ºC)Cold lead2.5m length
Ordering Information
 230V
Length (m)Watts (12W/m)
Amps
ohmsCatalog NumberMiniCable/12-15012.51500.7352.7MiniCable/12-22518.82251.0235.1MiniCable/12-30025.03001.3176.3MiniCable/12-37531.33751.6141.1MiniCable/12-45037.54502.0117.6MiniCable/12-52543.85252.3100.8MiniCable/12-60050.06002.688.2MiniCable/12-67556.36752.978.4MiniCable/12-75062.57503.370.5MiniCable/12-90075.09003.958.8MiniCable/12-105087.510504.650.4MiniCable/12-1200100.012005.244.1MiniCable/12-1350112.513505.939.2MiniCable/12-1500125.015006.535.3MiniCable/12-1800150.018007.829.4
Why Choose Jiahong :

22 years experience made us to be the biggest manufacturer of heating cable in Asia. The only one have CE UL ETL TUV CSA certificate  in Aisa. And 6-year's supplier of homedepot ,GE ,Grainger.

Products include heating mat ,heating cable ,thermostat and self regulating heating cable , All products approved and 100% inspected.Only adopts high-quality raw materials, key materials imported from American, Japan and Germany . It made our products with excellent quality .Better than any other competitors  in China .

25-year warranty for underfloor heating system, 10-year warranty for self-regulating  heating system; Deal and solve any of your concerns at the earliest time
Besides, we have a new cable only 2mm thickness.
