• Model NO.：FTTX
• Wire Core Material：Fiber
• Certification：CE, RoHS
• Model：FTTX
• Brand：Hanxin
• Transport Package：2000m
• Specification：800x800x500
• Trademark：hanxin
• Origin：Zhenjiang
• Production Capacity：5000000000m,Year

Basic Info.

Model NO. FTTX Wire Core Material Fiber Certification CE, RoHS Model FTTX Brand Hanxin Transport Package 2000m Specification 800x800x500 Trademark hanxin Origin Zhenjiang Production Capacity 5000000000m/Year

Product Description

Uni-Loose Tube All Dielectric Drop cable FTTH  Oval fiber optical cable

Product Description
Uni-Tube All Dielectric Aerial Drop cable is Especially designed for Fiber to the Subscriber applications. It is a flat, all dielectric cable ideally suited for self-supporting drop-type installations as well as conduit builds.
 Features
Small size, Low cost.
 Up to 2 fibers.
 Uni-tube gel-filled construction for superior fiber protection.
 Two parallel FRP wire and overall glass yarn to enhance tensile resistant.
 And protect cable from mechanical damage.
 Designed for use with inexpensive attachment hardware.
 Self-supported no messenger needed.
Applications

Cable Properties
No.of Fibres: 2
Colour Of Fibre: Blue,Orange,Green,Brown,Slate,White,Red,Black,Yellow,Violet,Aqua&Pink
Loose Tube Diameter: 1.9 mm (PBT)
Type Of Fiber: SM G652D
Strength Member: 2 FRP ROD (2mm)
Sheath Material: HDPE
Sheath Colour: Black
Sheath Thickness: 1.5 mm Nominal
Cable Dimnsions --Height:  5.0+/-0.3 mm
                               --Width:   9.0+/-0.3 mm
 Cable Weight: 52+/- 5Kg/Km
Tensile Strength--Installation:  Newton 1500
                            --Operating:  Newton   700
Crush Resistance (Short Term): Newton/10cm   1500
Temperature Performance Operating /Installation: -40 to + 70 ºC
Packing Length: 4 KM +/-10%
Printing On Cable: As Per Customer Requirement
