• Model NO.：0.6,1kv 4 core Aluminum conductor XLPE insulation
• Material Shape：Round Wire
• Range of Application：Underground
• Certification：ISO9001, CE, CCC, RoHS
• Brand：Hongda
• Relate Voltage：0.6,1kv
• Key Word：Aluminum Power Cable
• Transport Package：Wooden Drum and Steel Wooden Drum
• Specification：4 core aluminum XLPE power cable
• Trademark：hongda cable
• Origin：Henan China
• Production Capacity：500000

Basic Info.

Model NO. 0.6/1kv 4 core Aluminum conductor XLPE insulation Material Shape Round Wire Range of Application Underground Certification ISO9001, CE, CCC, RoHS Brand Hongda Relate Voltage 0.6/1kv Key Word Aluminum Power Cable Transport Package Wooden Drum and Steel Wooden Drum Specification 4 core aluminum XLPE power cable Trademark hongda cable Origin Henan China Production Capacity 500000

Product Description

product description :




Cable size	Conductor type	Nominal thickness of XLPE insulation (mm)	Approx. diameter of steel wire(mm)	Nominal thickness of PVC or PE sheath(mm)	Approx. cable overall diameter (mm)	Max. D.C resistance @ 20ºC(Ω/km)
4x1.5mm 2	RE or RM	0.7	0.8	1.8	14.5	18.1
4x2.5mm 2	RE or RM	0.7	1.25	1.8	16.4	12.1
4x4mm 2	RE or RM	0.7	1.25	1.8	17.5	7.41
4x6mm 2	RE or RM	0.7	1.25	1.8	18.7	4.61
4x10mm 2	RM	0.7	1.6	1.8	22.5	3.08
4x16mm 2	RM	0.7	1.6	1.8	25.1	1.91
4x25mm 2	SM	0.9	1.6	1.8	26.9	1.20
4x35mm 2	SM	0.9	1.6	1.9	29.2	0.868
4x50mm 2	SM	1.0	2.0	2.0	33.4	0.641
4x70mm 2	SM	1.1	2.0	2.2	37.4	0.443
4x95mm 2	SM	1.1	2.0	2.3	41.7	0.320
4x120mm 2	SM	1.2	2.5	2.4	46.2	0.253
4x150mm 2	SM	1.4	2.5	2.6	50.7	0.206
4x185mm 2	SM	1.6	2.5	2.8	55.8	0.164
4x240mm 2	SM	1.7	2.5	3.0	62.0	0.125
4x300mm 2	SM	1.8	3.15	3.1	87.6	0.10
