• Model NO.：H07BN4-F
• Material Shape：Round Wire
• Range of Application：Wind Energy
• Certification：ISO9001, CE, CCC, RoHS, VDE, TUV
• Brand：Fengda
• Colour：Red,Green,Blue,Black,White,as Request
• Flame Test：Yes
• OEM/ODM：Accepted
• Core：Single Core and Multicore
• Factory Type：Manufacturer
• Transport Package：Rolls or According to Cusotmers′ Reques
• Specification：0.12 to 400mm2
• Trademark：FengDa
• Origin：Tianjin, China(Mainland)
• HS Code：8544492100
• Production Capacity：5000000km,Year

APPLICATION
Flexible rubber cable with high temperature resistance suitable
for most industrial applications such as connecting equipment.
The mains supply and generally for use in arduous industrial
environments where good flexibility and resistance mechanical
abrasion is essential.
CHARACTERISTICS
Voltage Rating U/Uo
450/750V
The use of up to 1kV in alternative current is authorised for protected static installations and for the connection of motors in lifting appliances
Temperature Rating
Fixed: -40°C to +90°C
Flexed: -15°C to +90°C
Minimum Bending Radius
Up to 25mm² - Flexed: 6 x overall diameter
Above 25mm² - Flexed: 8 x overall diameter
CONSTRUCTION
Conductor
Class 5 flexible tinned copper conductor
Insulation
EPR (Ethylene Propylene Rubber)
Sheath
HOFR CSP (Heat and Oil Resistant and Flame Retardant Chlorosulphonated Polyethylene)
Sheath Colour
 Black
DIMENSIONS
