• Model NO.：240mm
• Wire Core Material：Red Copper Wire
• Certification：ISO, CCC, CE
• Model：YJV
• Brand：Yifang
• Size：up to 800mm2
• Alternative Voltage：up to 35kv
• Armour：Swa or Sta
• Transport Package：Wooden Drum
• Specification：CE
• Trademark：yifang
• Origin：Zhengzhou, China
• HS Code：8544601200
• Production Capacity：300km,Month

China Type
Description
Application
Cu
Al
YJV
YJLV
XLPE insulation PVC sheath power cable (Cu/XLPE/PVC)
To be laid indoors, in tunnel, cable furrow or pipe, the cable couldn't bear mechanical force outside
YJY
YJLY
XLPE insulation PE sheath power cable (Cu/XLPE/PE)
YJV22
YJLV22
 XLPE insulation, steel tape armor,  PVC sheath power cable
(Cu/XLPE/PVC/STA/PVC)
To be laid underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force.
YJV23
YJLV23
XLPE insulation, steel tape armor,  PE sheath power cable
(Cu/XLPE/PVC/STA/PE)
YJV62
YJLV62
XLPE insulation,  no  magnetism steel tape armor,  PE sheath power cable
YJV32
YJLV32
XLPE insulation, thin steel-wire  armor,  PVC sheath power cable
(Cu/XLPE/PVC/SWA/PVC)
Be applicable to the well, water inside and fall in the bad soil, the cable cans bear the equal dint outside the machine with pull the dint
.
YJV72
YJLV72
XLPE insulation, have no the magnetism thick steel-wire  armor,  PVC sheath power cable
YJV42
YJLV42
XLPE insulation, thick steel-wire  armor,  PVC sheath power cable
Be applicable to the well, underwater with the bottom of sea, the cable cans bear the bigger pressure with lead to pull the dint.

Specifications
1.Voltage: 1kv to 35kv
2. ISO, CCC Certificate
3. 22 years producing experience
4.Professional service
We can customize various types of cable in accordance with your requirements
XLPE  /PVC insulated power  cable
Mode and name
 Power cable
Model
                       Name
YJV
YJLV
CU or AL conductor ,XLPE/pvc  insulated PVC sheathed electric cable
YJV22
YJLV32
Cu or Al conductor XLPE /pvc insulated steel tape armoured ,steel wire armor
pvc sheathed electric cable
 We can produce 1kv up to 35kv power cable

XLPE insulated power cable 0.6/1kvnorminalsectional area insulati-on thicknessheath thickness(mm)
overal diameter
of cable (mm)
D.C resistance of conductor(km)                current ratingin air(A)direct in soil(A)cuAlcuAlcuAl1×1.50.71.56<=12.1<=12.1302545351×40.71.57<=7.41<=7.41453560501×60.71.57<=3.08<=4.61554570551×350.91.512<=0.524<=0.8681751401901501×5011.513<=0.387<=0.6412101702251801×701.11.514<=0.268<=0.4432702152802251×951.11.516<=0.193<=0.3203402753352701×1201.21.518<=0.153<=0.2534003203803051×1501.4221<=0.124<=0.2064603704253401×1851.6223<=0.0991<=0.1645304154803751×2401.7225<=0.0754<=0.125625490555435









3×1.50.71.510<=12.1<=12.1252530303×2.50.71.511<=7.41<=12.1302535303×40.71.512<=4.61<=7.4140305040









Attention: We can provide more info than above data, if needed.The above are just some examples.
