4core 25mm 50mm 95mm 120mm Aluminum ABC Cable
Henan Hongda Cable Co., Ltd.- Application：Construction, Overhead, Industrial, Power Station, ABC AAC AAAC ACSR Conductor Specification of 3 Cor
- Voltage：Low and Medium Voltage Cable
- Current：AC Cable
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：BS 7870
- Wire Core Material：Aluminum Conductor
- Certification：ISO, CCC, CE, ABC AAC AAAC ACSR Conductor Specification of 3 Cor
- Model：ABC Cable
- Brand：Henan Hongda
- Insulation Color(S)：Natural , Red , Yellow , Blue , Green etc.
- Outer Sheath Color：Black etc.
- No. of Cores：4
- Cross Section：25mm 50mm 95mm 120mm
- Packing Length：According to Your Request
- Long‐term Working Temperature：90°c
- Max. Temperature in Short Circuit：160°c ,250°c
- Rated Voltage：300,300V, 300,500V, 450,750V, 0.6,1kv
- Design Standard：IEC 60502-1, IEC 60502-2, IEC 60227, IEC 60228
- Warranty：3 Year
- Certificate：ISO 14001 , ISO 9001 , Ohasa 18001 , CCC
- Transport Package：by Sea
- Specification：ABC AAC AAAC ACSR conductor specification of 3 cor
- Trademark：HENAN HONGDA
- Origin：China
- HS Code：85444929
- Production Capacity：3000
Description
YJV CU/XLPE/PVC
YJLV
AL/XLPE/PVCmm2 mm mm mm mm kg/km kg/km A A A A 4×1.5 RE 1.38 0.7 1.8 10.9 157.8 120.5 21 - 26 - 4×2.5 RE 1.78 0.7 1.8 11.9 205.1 142.9 28 21 35 26 4×4 RE 2.24 0.7 1.8 13.0 272.3 172.8 37 28 46 35 4×6 RE 2.76 0.7 1.8 14.2 371.0 221.8 47 37 56 46 4×10 CC 3.8 0.7 1.8 16.8 543.9 295.2 64 49 76 59 4×16 CC 4.8 0.7 1.8 19.2 787.2 389.2 84 64 98 78 4×25 CC 6.0 0.9 1.8 23.0 1188.9 567.1 115 87 126 98 4×35 CC 7.0 0.9 1.8 25.4 1577.4 706.9 141 120 152 130 4×50 SM 8.0 1.0 1.9 26.1 2134.8 891.2 172 151 181 161 4×70 SM 9.5 1.1 2.0 30.1 2931.8 1190.8 218 183 222 192 4×95 SM 11.0 1.1 2.1 33.5 3895.1 1532.3 269 238 267 234 4×120 SM 12.4 1.2 2.3 36.6 4874.6 1890.0 313 285 305 276 4×150 SM 13.8 1.4 2.4 40.9 6078.8 2348.1 359 328 344 318 4×185 SM 15.4 1.6 2.6 46.5 7492.1 2890.8 405 375 383 351 4×240 SM 17.5 1.7 2.8 51.1 9619.9 3650.7 451 405 422 376 4×300 SM 19.6 1.8 3.0 56.3 11943.2 4481.7 491 422 461 394
Phase conductors :Round standed or compacted 1350-H19 aluminium or Copper conductor ,AAAC,ACSR
Neutral or messenger conductor :Round standed or compacted 6201 aluminium alloy or AAC ,ACSR
Street lighting conductor: Round standed or compacted Aluminium conductor
Insulation : LDPE ,HDPE,XLPE ,PVC ( UV-resistant)
Note: The above provisions can be changed as order
Overhead line wire (Aerial line) Technical parameterTNB Standard (IEC 60502) Aerial Bundled Conductor (ABC) Cables
YJLV
AL/XLPE/PVC
Phase conductors :Round standed or compacted 1350-H19 aluminium or Copper conductor ,AAAC,ACSR
Neutral or messenger conductor :Round standed or compacted 6201 aluminium alloy or AAC ,ACSR
Street lighting conductor: Round standed or compacted Aluminium conductor
Insulation : LDPE ,HDPE,XLPE ,PVC ( UV-resistant)
Note: The above provisions can be changed as order
