Self-Regulating Heating Cables Roof and Gutter Downspouts De-Icing Electric Heat Cable

Wuhu Jiahong New Material Co., Ltd.
  • Service Voltage：110-120V,208-277V
  • Maximum Maintain or Continuous Temp：65 Degree
  • Maximum Intermittent Exposure Temp：85 Degree
  • Minimum Installation Temperture：Zero 40 Degree
  • Protective Braid Resisitance：<18.2 Ω,Km
  • Bus Wire Gauge：16AWG

Base Info

  • Model NO.：HTR
  • Approvals：CE, cULus, Iecex, Atex,Eac,CSA
  • Transport Package：Innner Carton Master Carton
  • Specification：11.0*4.4mm
  • Trademark：jiahong
  • Origin：Anhui Wuhu
  • HS Code：85168000
  • Production Capacity：50000PCS Per Day

Description

Technical DataService voltage110-120V, 208-277VMaximum maintain or continuous
exposure temperature(power on)  +65ºC(150ºF)Maximum intermittent exposure
Temperature, 1000 hours
(power on or off)    +85ºC(185ºF)Minimum installation temperature -40ºC(-40ºF)Protective braid resistance  <18.2Ω/kmBus wire gauge16AWGApprovals    UL / CSA / ETL / IECEx / ATEX / EAC /CE

Dimension and weightTypeDimensionWeight  (kg/100m)HTR…C11.0×4.4mm9.2HTR…CR12.6×6.0mm12.0HTR…CT12×5.4mm11.2Self-Regulating Heating Cables Roof and Gutter Downspouts De-Icing Electric Heat Cable
WHY WUHUJIAHONG

25 years experience made us to be the biggest manufacturer of heating cable in Asia. The only one have CE UL ETL TUV  CSA certificate in Aisa. And 6-year's supplier of homedepot, GE, Grainger.
Products include heating mat, heating cable, thermostat and self regulating heating cable.
All products approved and 100% inspected.
Only adopts high quality raw materials, key materials imported from American, Japan and Germany.
It made our products with excellent quality. Better than any other competitors in China.

25-year warranty for underfloor heating system, 10-year warranty for self-regulating  heating system; Deal and solve any of your concerns at the earliest time
Besides, we have a new cable only 2mm thickness.
