Multi Cores 2core 3core 4core 5core 6core UL2405 Twisted Shield Cable
B&T (Zhangzhou) Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Lighting, Lamb
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PE
Base Info
- Model NO.：UL2405
- Material Shape：Flat Wire
- Range of Application：Flame Retardant
- Certification：UL, RoHS
- Brand：Bort
- Packaging：1000FT,Spool
- Weight：About 1kg,1000FT
- Color Available：Any Colors
- Delivery Time for Samples：3-5days
- Delivery Time for Mass Production：7-10days
- Appliance：Low Energy Non-Hazardous Circuits in a,V Equipment
- Warranty Time：at Least 10years for Proper Use
- Standard of Production：RoHS & Reach
- Factory Management Standard：ISO9001:2008
- Annual Capacity：300,000kms
- Transport Package：Coiled in The Plastic Spool
- Specification：40-10AWG
- Trademark：BoRt
- Origin：Zhangzhou, China
- HS Code：8544492900
- Production Capacity：300000kms
Description
Maximum Resistance at 20 ºC
Ω/kmAWG No./mm Dia.
mm Nom. Thick.
mm Nom.Dia.
mm Braid Shield
No./No./mm Nom. Thick.
mm Nom.Dia.
mm 2 30 7/0.1 0.30 0.41 1.12 56/0.12 0.45 3.38 354 28 7/0.127 0.38 0.41 1.20 60/0.12 0.45 3.54 223 26 7/0.16 0.48 0.43 1.34 57/0.12 0.45 3.82 139 24 11/0.16 0.61 0.41 1.43 71/0.12 0.45 4.00 88.9 22 17/0.16 0.76 0.43 1.62 70/0.12 0.45 4.38 57.5 22 7/0.254 0.76 0.41 1.58 78/0.12 0.45 4.30 57.5 20 26/0.16 0.94 0.41 1.76 88/0.12 0.45 4.65 34.6 18 41/0.16 1.18 0.43 2.04 16/7/0.1 0.54 5.22 23.3 18 16/0.254 1.18 0.41 2.00 99/0.12 0.45 5.14 23.3 16 26/0.254 1.50 0.41 2.32 115/0.12 0.45 5.78 15.1 3 30 7/0.1 0.30 0.41 1.12 63/0.12 0.45 3.55 354 28 7/0.127 0.38 0.41 1.20 68/0.12 0.45 3.72 223 26 7/0.16 0.48 0.41 1.30 73/0.12 0.45 3.94 139 24 11/0.16 0.61 0.43 1.47 79/0.12 0.52 0.450 88.9 22 17/0.16 0.76 0.41 1.58 89/0.12 0.45 4.54 57.5 20 26/0.16 0.94 0.41 1.76 99/0.12 0.45 4.93 34.6 18 41/0.16 1.18 0.41 2.00 113/0.12 0.45 5.45 23.3 4 30 7/0.1 0.30 0.41 1.12 71/0.12 0.45 3.84 354 28 7/0.127 0.38 0.41 1.20 76/0.12 0.45 4.04 223 26 7/0.16 0.48 0.41 1.30 82/0.12 0.45 4.28 139 24 11/0.16 0.61 0.41 1.43 90/0.12 0.45 4.59 88.9 22 17/0.16 0.76 0.41 1.58 100/0.12 0.45 4.95 57.5 20 26/0.16 0.94 0.41 1.76 111/0.12 0.45 5.39 34.6 5 30 7/0.1 0.30 0.41 1.12 79/0.12 0.45 4.16 354 28 7/0.127 0.38 0.41 1.20 85/0.12 0.45 4.38 223 26 7/0.16 0.48 0.41 1.30 92/0.12 0.45 4.65 139 24 11/0.16 0.61 0.41 1.43 100/0.12 0.45 5.00 88.9 22 17/0.16 0.76 0.41 1.58 112/0.12 0.45 5.41 57.5 6 30 7/0.1 0.30 0.41 1.12 88/0.12 0.45 4.50 354 28 7/0.127 0.38 0.41 1.20 94/0.12 0.45 4.74 223 26 7/0.16 0.48 0.41 1.30 102/0.12 0.45 5.04 139 24 7/0.2 0.60 0.41 1.42 112/0.12 0.45 5.40 88.9 24 11/0.16 0.61 0.41 1.43 112/0.12 0.45 5.43 88.9
Ω/km
mm
mm
mm
No./No./mm
mm
mm
