UL10533 Single Core Multi Strand Flexible Copper Cable Frpe Insulation Electric Wire

B&T (Zhangzhou) Cable Co., Ltd.
  • Rated Temperature：80 ºC
  • Rated Voltage：300V
  • According to：UL Subject758, UL1581, C22.2
  • Test：Passes UL VW-1 & CSA FT1 Vertical Flame Test
  • Performance：for General Purpose Internal Wiring of Appliance
  • Conductor：Stranded, Tinned or Bare Copper Conductor

Base Info

  • Model NO.：UL10533
  • Capacity：300,000km Annual
  • Color：Could Be Customized Color
  • Delivery Time：7-15days
  • Package：Coil or Spool Packing
  • Transport Package：610feet in Roll
  • Specification：UL1061
  • Trademark：B&T
  • Origin：Xiamen, Fujian
  • HS Code：8544492100
  • Production Capacity：300, 000km

Description

(mm)   Nom.Min.Nom.Tol.1619/0.28714.60 1.50 0.25 0.23 2.00 ±0.101819/0.23523.20 1.18 0.25 0.23 1.70 ±0.102019/0.1936.70 0.95 0.25 0.23 1.45 ±0.102219/0.1559.40 0.76 0.25 0.23 1.26 ±0.10247/0.2094.20 0.60 0.25 0.23 1.10 ±0.10267/0.16150.00 0.48 0.25 0.23 1.00 ±0.10287/0.127239.00 0.38 0.25 0.23 0.90 ±0.10301/0.254361.00 0.254 0.25 0.23 0.75 ±0.10
