LAN Cable CAT6A, 500 MHz, 23AWG, Solid Bare Copper CAT6A
Zhejiang Kuayue Cable Co., Ltd.- Application：Local Communication Cable, LAN Cable, Long Distance Symmetric Cable
- Conductor Material：Copper
- Cover Material：PVC
- Type：CAT6A
- Material Shape：Flat Wire
- Conductor Type：Solid
Base Info
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS
- Model：Hanli
- Brand：Hanli
- Model No：CAT6A 1000 FT 23 AWG,UL,Cmr,UTP,Bare Copper
- Transport Package：305m,Box
- Specification：CAT6A
- Trademark：hanli
- Origin：Zhejiang
- HS Code：8544491100
- Production Capacity：3000000m,Month
Description
Lan Cables
Welcome to visit our factory and get our samples.
Your inquiry will be answered within 24 hours .Wishing to be your long- term partner ,please feel free to contact me ,we will do our best for you.
Choose us, won't make you disappointed:
1.6years manufactory experience
2.OEM/ODM available
3.Steady product quality
4.Strict quality control
5.Strictly conform to CE,ROHS,Iso9001
6.Quick delivery time(20ft,25days)
Website: http://kuayuecable.en.made-in-china.com http://kuayuecable.en.made-in-china.com
| SFTP CA6A | ||||||
| Product Name/Code: SFTP Cat6A | ||||||
| Frequency | RL | Attenuation | NEXT | PSNEXT | ||
| 100 Base-T4 | (MHz) | (dB) | (dB/100m) | |||
| 100 Base-TX | min. | max | min (dB) | min (dB) | ||
| 100VG - AnyLAN | 1.000 | 20.00 | 2.00 | 80.00 | 77.00 | |
| 1000 Base-T (Gigabit Ethernet) | 4.000 | 23.00 | 3.60 | 80.00 | 77.00 | |
| 155 Mbps ATM | 10.00 | 25.00 | 5.70 | 80.00 | 77.00 | |
| 622 Mbps AT | 16.00 | 25.00 | 7.20 | 80.00 | 77.00 | |
| Reference Standard | 20.00 | 25.00 | 8.10 | 80.00 | 77.00 | |
| EIA/TIA 568B & ISO/IEC 11801 | 31.25 | 23.60 | 10.10 | 80.00 | 77.00 | |
| Cable Construction | 62.50 | 21.50 | 14.50 | 75.50 | 72.50 | |
| Conductor | Solid Bare Copper | 100.00 | 20.10 | 18.50 | 72.40 | 69.40 |
| AWG | 23 | 200.00 | 18.00 | 26.80 | 67.90 | 64.90 |
| Conductor Diameter(mm) | 0.574 | 250.00 | 17.30 | 30.20 | 66.50 | 63.50 |
| Insulation | Solid PE/F.PE | 300.00 | 17.30 | 33.30 | 65.30 | 63.30 |
| 600.00 | 17.30 | 48.90 | 60.80 | 57.80 | ||
| Average Thickness (mm) | 0.2 | Frequency | ELFEXT | PSELFEXT | ACR | |
| Insulation Diameter(mm) | 1.35 | (MHz) | ||||
| min (dB) | min (dB) | |||||
| 1.000 | 80.00 | 77.00 | 78.00 | |||
| Diameter(mm) | 9.1(22 AWG) | 31.25 | 64.10 | 61.10 | 69.90 | |
| 8(23 AWG) | 62.50 | 58.10 | 55.10 | 61.00 | ||
| Core Identificatin/Color Code | According to customer request | 100.00 | 54.00 | 51.00 | 53.90 | |
| Bending Radius | 6xOverall Diameter | 200.00 | 48.00 | 45.00 | 41.10 | |
| 250.00 | 46.00 | 43.00 | 36.30 | |||
| 300.00 | 44.50 | 41.50 | 32.00 | |||
| 600.00 | 38.40 | 35.40 | 11.90 | |||
| Fire Performance | Electrical Performance | |||||
| Flame propagation Test to IEC 332 Part 1(PVC) Flame Propagation Test to IEC 60332 Part 1 and Part 3(FEPVC) | Max.Conductor DC Resistance at 20 ºC(Ω/Km) | <93.8 | ||||
| Operating Temperature( ºC ) | 70 | |||||
| Velocity of propagation | 79% | |||||
| Impedance(ohm) | 100±15 | |||||
