Single Fiber Bidi Devices
GYSUNTEC TECHNOLOGY CO., LTD.- Application：Communication, Sensor
- Type：Single-mode Fiber
- Connection Structure：FC
- Material Shape：Round Wire
- Allowed Lateral Pressure：100(N,100mm)<1000(N,100mm)
- Allowed Tensile Strength：100N<1000N
Base Info
- Model NO.：GYQ574950-754B-**, GYQ57D550-744B-**
- Core：Single Core
- Certification：RoHS, UL, CE, ISO9001, CCC
- Brand：OEM
- Sheath Material：PC
- Transport Package：ESD Packing and Standard Paper Box
- Specification：RoHS, CE, FCC
- Trademark：GYsuntec or OEM
- Origin：China
- Production Capacity：100kpcs,Month
Description
Transmitter Specifications(Tc=25'C,unless otherwise specified)Parameter Symbol Min Typ Max Unit Center wavelength GYQ574950-754B-** Λ o 1480 1490 1500 nm GYQ57D550-744B-** Λ o 1530 1550 1570 nm Optical output power( I op =I th +20mA) P 0 0 - - dBm Side Mode Suppression ratio SMSR 35 - - dB Operating voltage V OP - 1.1 1.5 V Threshold current I th - 7 18 mA Operating current I OP - 30 50 mA Spectral width Δλ - - 1 nm Rise and fall time T r , T f - - 0.2 ns Monitor Current Im 0.1 - - mA Connector Loss IL1550nm - - 0.5 dB Connector Reflection RC1550nm - - -40 dB Receiver Specifications(Tc=25'C,unless otherwise specified) Parameter Symbol Min Typ Max Unit wavelength GYQ574950-7O4B-PSA Λ o 1530 1550 1570 nm GYQ57D550-7L4B-PSA Λ o 1470 1490 1510 nm APD Breakdown Voltage(Id=10uA) VBR 33 46 V TIA Supply voltage V CC 3 3.3 3.6 V TIA Supply current I CC - 20 25 mA Bandwidth BW 1.65 - - GHz Saturation power (1550nm) Psat -7 - - dBm Sensitivity Sen - - -32 dBm one pair GYQ55F510-533C-** 155Mbps 1550nm FP 1310nm PIN-TIA MMF ST,FC,ST,LC Receptacle,or Pigtail -22~-12dBm ≤-30dBm GYQ55F330-553C-** 155Mbps 1310nm FP 1550nm PIN-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail -8~-3dBm ≤-35dBm one pair GYQ55F530-533C-** 155Mbps 1550nm FP 1310nm PIN-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail -8~-3dBm ≤-35dBm GYQ554950-553A-** 155Mbps 1490nm DFB 1550nm PIN-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail ≥0dBm ≤-38dBm one pair GYQ55D550-543A-** 155Mbps 1550nm DFB 1490nm PIN-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail ≥0dBm ≤-38dBm GYQ55F340-543C-** 155Mbps 1310nm FP 1490nm PIN-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail -3~0dBm ≤-35dBm one pair GYQ554940-533C-** 155Mbps 1490nm DFB 1310nm PIN-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail -3~0dBm ≤-35dBm GYQ57F340-753B-** 1.25Gbps 1310nm FP 1550nm PIN-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail -3~0dBm ≤-25dBm one pair GYQ57D540-733B-** 1.25Gbps 1550nm DFB 1310nm PIN-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail -3~0dBm ≤-25dBm GYQ574950-753B-** 1.25Gbps 1490nm DFB 1550nm PIN-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail ≥0dBm ≤-25dBm one pair GYQ57D550-743B-** 1.25Gbps 1550nm DFB 1490nm PIN-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail ≥0dBm ≤-25dBm GYQ574950-754B-** 1.25Gbps 1490nm DFB 1550nm APD-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail ≥0dBm ≤-32dBm one pair GYQ57D550-744B-** 1.25Gbps 1550nm DFB 1490nm APD-TIA SMF ST,FC,ST,LC Receptacle,or Pigtail ≥0dBm ≤-32dBm
