• Model NO.：FCW
• Trademark：jiahong
• Origin：Anhui Wuhu
• Production Capacity：17000PCS Per Day

PCECCE11.50 16U
Exe IIC GB/DIP A22 IP65IECExIECEx LCI 11.0071U
EX e llc Gb
EX t lllc Db IP65ATEXLCIE 11 ATEX 3094 U
  II 2 GD
EX e llc Gb
EX t lllc Db IP65
Specifications Area classificationHazardous,Zone 1,Zone 2 (Gas),Zone 21,Zone  22(Dust)Trna classificationCarbon steel Stainless steel
Painted or unpainted metalChemical resistanceOrganics and corrosices
For aggressive organics and corrosives consult your jiahong representativeSupply voltage230Vac(Contact your local jiahong representative for data on other voltages)Minimum                             installation temperature-40 CMinimum bend radius50 mm
Performance and Rating Data Catalog NumberService VoltageOutput W/mMaximum Length/mMax.Maintenance Temperature/ CMax.Exposure Temperature/ C
FCW-1022010.021015020523011.021015020524011.9210150205
FCW-2022020.018012020523022.018011520524023.8180110205
FCW-3022030.01509020523033.01508020524035.715075205
FCW-4022040.01406520523045.01406020524047.6140--205
Performance and Rating DataCatalog NumberService VoltageOutput W/m 15A20A30A
FCW-1022010.0210----23011.0210----24011.9210----
FCW-2022020.0165180--23022.0155180--24023.8150180--
FCW-3022030.011014515023033.010514015024035.7100135150
FCW-4022040.08011014023045.07810514024047.675100140
Company Information
1.About Us
WuHu Jiahong New Material Co. Ltd is the largest heating cable manufacturer in Asia-pacific. We are always dedicated to research, develop and produce both constant wattage and self-regulating heating cables since 1993. Till now, Jiahong has obtained more than 30 national patents. We are one of the few members of China self-regulating heating cable national standard GB/T 19835-2005.
Most of WuHu Jiahong products passed UL, CSA, ETL, TUV, CE, ATEX etc. We export to many regions, especially North America, Europe, Australia and Asia. High quality combines with professional services earned us a good reputation.

FAQ
 1.How long will it take for the underfloor heating system to warm up?The warm up time of an electric underfloor heating system will be dictated by the insulation used beneath it and the output of the system. In general, the better insulated the sub-floor the faster the system will warm up, with Underfloor Insulation boards?facilitating a very speedy warm up time of as little as 15 minutes, and un-insulated concrete floors causing the slowest warm up time. Using a?200W system?beneath ceramic/stone tiles provides a faster warm up time than 150W system.
2. Can I turn my heating on the day it is fitted? If you have installed your heating beneath tile adhesive, levelling compound or a screed you must allow this to dry out before turning on your system for the first time. If the system is turned on too early it will force the moisture out of the covering which may lead it to crack. We would recommend speaking to the manufacturer of your flexible tile adhesive, grout or screed to confirm the drying time required.
3. Does each room require its own thermostat?We would recommend that each room has its own heating system controlled by its own thermostat. This will allow for simpler and more accurate temperature control of each room and will avoid heating rooms which do not require it.
