Sales Promotion FTTH Lszh Indoor Cable
Wuhan Seifree Technology Co., Ltd.- Type：Optical Fiber Distribution Box
- Certification：ISO
- Size：Plastic Box
- Wiring Devices：ODF
- Condition：New
- Transport Package：Standard Packing or Customer Required
Base Info
- Model NO.：LSZH
- Specification：RoHS
- Trademark：Seifree
- Origin：Wuhan, Hubei. China
- Production Capacity：100000PCS,Year
Description
G.652
G.655
50/125μm
62.5/125μm
Attenuation
(+20ºC)
@850nm
≤3.0 dB/km
≤3.0 dB/km
@1300nm
≤1.0 dB/km
≤1.0 dB/km
@1310nm
≤0.36 dB/km
≤0.40 dB/km
@1550nm
≤0.22 dB/km
≤0.23dB/km
Bandwidth (Class A)
@850nm
≥500 MHz·km
≥200 MHz·km
@1300nm
≥1000 MHz·km
≥600 MHz·km
Numerical Aperture
0.200±0.015NA
0.275±0.015NA
Cable Cut-off Wavelength λcc
≤1260nm
≤1480nm
·Technical Parameters
ber Count | Cable Diameter mm | Cable Weight kg/km | Tensile Strength Long/Short Term N | Crush Resistance Long/Short Term N/100mm | Bending Radius Static /Dynamic mm |
1 | (2.0±0.2)×(3.0±0.2) | 8 | 30/60 | 300/1000 | 15/30 |
2 | (2.0±0.2)×(3.4±0.2) | 8.5 | 30/60 | 300/1000 | 15/30 |
1 | (2.0±0.2)×(3.8±0.2) | 9 | 30/60 | 300/1000 | 15/30 |
4 | (2.0±0.2)×(4.0±0.2) | 10 | 30/60 | 300/1000 | 15/30 |
Storage/Operating Temperature : -20ºC to + 60ºC
