• Model NO.：33kV Aluminum Power Cable
• Wire Core Material：Al
• Certification：ISO, CCC, CE
• Model：Yjlv32
• Brand：Yifang Cable
• Jacket Color：Red
• Armour：Galvanized Steel Wire
• Metallic Screen：Copper Tape
• Transport Package：Drum, Reel or According to Cusotmer′s Request
• Specification：1*50mm2 to 3*500mm2
• Trademark：Yifang
• Origin：Henan, China
• HS Code：8544600000
• Production Capacity：50, 000, 000km,Year

ModelDescriptionApplication Cu coreAl coreYJVYJLVXLPE insulation PVC sheath power cableTo be laid indoors, in tunnel, cable furrow or pipe, the cable couldn't bear mechanical force outside YJYYJLYXLPE insulation PE sheath power cableYJV22YJLV22 XLPE insulation, steel tape armor,  PVC sheath power cable
To be laid underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force.YJV32YJLV32XLPE insulation, thin steel-wire  armor,  PVC sheath power cableBe applicable to the well, water inside and fall in the bad soil, the cable cans bear the equal dint outside the machine with pull the dint
 YJV42YJLV42XLPE insulation, thick steel-wire  armor,  PVC sheath power cableBe applicable to the well, underwater with the bottom of sea, the cable cans bear the bigger pressure with lead to pull the dint.
(2) Specs of 33kv xlpe cable
Type
 No of CoresRated Voltage U( kV)33kVConductor cross-section mm2YJV  YJV32(42)
150-500YJLV  YJLV32(42)50-630YJV22 YJLV22 YJV  YJV22
350-300YJLV  YJLV2250-300YJV32  YJLV3250-300YJV42  YJLV4250-300
18/30(36)kV,19/33(36)kV,Three Cores,Al or Cu/XLPE/CTS/STA/PVC Armoured Power CableNo.X Nominal Cross Section of ConductorNominal Diameter of ConductorNominal Thickness of InsulationNominal Thickness of Copper Tape ScreenNominal Thickness of Inner SheathNominal Thickness of Steel Tape ArmouringNominal Thickness of PVC SheathApprox. Overall DiameterApprox. WeightAl ConductorCu ConductorNo. X mm2mmmmmmmmmmmmmmkg/mkg/m3 X 25         3 X 35         3 X508.28.00.11.70.52.870.44.565.413 X 709.78.00.11.70.52.973.95.046.263 X 9511.38.00.11.80.53.077.75.627.323 X 12012.88.00.11.90.83.282.86.999.153 X 15014.28.00.11.90.83.285.87.5610.263 X 18515.98.00.12.00.83.389.98.3011.673 X 24018.38.00.12.10.83.595.79.3613.793 X 30020.48.00.12.20.83.6100.610.5116.073 X 40023.28.00.12.30.83.8107.211.9919.073 X 50026.48.00.12.40.84.0120.114.1523.85

18/30(36)kV,19/33(36)kV,Three Cores,Al or Cu/XLPE/CTS/PVC Unarmoured Power CableNormal Cross Section of ConductorNormal Diameter of ConductorNormal Thickness of InsulationNormal Thickness of
Copper TapeNormal Thickness of Outer SheathApprox.
Overall Dia.Approx. Net WeightMax. D.C. Resistance of Conductor at 20°CAl ConductorCu ConductorAl ConductorCu Conductormm2mmmmmmmmmmkg/mkg/mΩ/kmΩ/km25         35         508.28.00.12.964.93.023.870.64100.4936709.78.00.13.068.43.424.650.44300.34209511.38.00.13.172.03.895.590.32000.246412012.88.00.13.375.74.396.540.25300.195515014.28.00.13.378.74.857.550.20600.158718515.98.00.13.482.65.428.790.16400.127124018.38.00.13.588.06.2210.660.12500.097630020.48.00.13.792.97.2012.770.10000.077840023.28.00.13.999.38.3815.460.07780.061550026.48.00.14.2107.610.1518.850.06050.0487
