IDC 2.0mm Pitch /1.0 Pitch Gray Flat Ribbon Cable

DONGGUAN KOTOBO INDUSTRY CO., LTD.
  • Application：Local Communication Cable, Computer
  • Conductor Material：Copper
  • Cover Material：PVC
  • Type：Connection
  • Material Shape：Round Wire
  • Conductor Type：Stranded

Base Info

  • Model NO.：custom
  • Wire Core Material：Stranded Conductor
  • Certification：ISO, RoHS, UL
  • Model：Customized as Customer
  • Brand：Kotobo
  • Transport Package：Plastic Bag The Outer Box Is a Carton
  • Specification：according to customer specification
  • Trademark：KOTOBO
  • Origin：China
  • HS Code：8544302001
  • Production Capacity：10000000,Month

Description

Basic Info.

Model NO. custom Wire Core Material Stranded Conductor Certification ISO, RoHS, UL Model Customized as Customer Brand Kotobo Transport Package Plastic Bag The Outer Box Is a Carton Specification according to customer specification Trademark KOTOBO Origin China HS Code 8544302001 Production Capacity 10000000/Month

Product Description

UL 2651 28awg flat cable IDC 2.0MM
Key specification
Insulation material : PVC
Conductor soze:7*0.12
current rating 1A
Volatage rating : 300Vrms
Temperature rating : -20C - +105C
Cable sides : sameside contact & opposite side contact
 Pin contact :6Pin-64Pin




IDC flat gray ribbon cable

KOTOBO has the capability& tooling to manufacture most froms of IDC (Insulation displacesment ) connector ribbon cable assemblies, the IDC flat ribbon cable connector system porvides a modular apporach to electrical interconnection . The modular design of IDC headers, sockets ect. offers a very reliable mass termination and cost effective apporach to interconnectiong PCBs, or wire-to- board, separable header/socket or dual-in-line applications, outstanding features are high contact reliability , long life and low contact resistance . IDC ribbon cables can be manufactured in may sizes the most popular being 10,16,26 and 34 ways, All our IDC ribbon cable assemblies are 100% tested for continuity and crossover using our electronic testers.

IDC ribbon cable assemblies can be supplied in standard gray and and rainbow-clored, it can be supplied in twisted pair or screened versions at lengths to your are given to customers, requirements with a quick turnaround, whilst most IDC ribbon cable is flat ,rond format versions are also available ,this style can also be supplied screened.

If you company has a requirement for IDC ribbon cable assemblies , please send through your enquiry . thank you!
