Mv XLPE Insulation Power Cable
YIFANG ELECTRIC GROUP INC.- Application：Construction, Underground, Power Station
- Voltage：Low and Medium Voltage Cable
- Current：AC Cable
- Insulation Material：XLPE
- Certification：ISO
- Transport Package：Drum, Reel or According to Your Request
Base Info
- Model NO.：YJV
- Specification：IEC, BS, DIN, ASTM, NFC, JIS etc
- Trademark：Yifang
- Origin：Zhengzhou, Henan, China
- HS Code：8544492100
- Production Capacity：50, 000km Per Month
Description
TypeDescription Main Application Copper Conductor Aluminum Conductor YJV
Cu/XLPE/PVC YJLV
Al/XLPE/PVC Copper or aluminum conductor
XLPE insulated, Copper tape
screen PVC sheathed power cable For laying indoor, tunnel, underground and cannel.
Unable to bear external mechanical pulling force and pressure during laid. YJV
Cu/XLPE/L(H)DPE YJLV
Al/XLPE/L(H)DPE Copper or aluminum conductor
XLPE insulated, Copper tape screen
PE/LDPE/HDPE sheathed power cable YJE
Cu/XLPE/LSOH YJLE
Al/XLPE/LSOH Copper or aluminum conductor XLPE
insulated, Copper tape
screen LSOH sheathed power cable YJSV
Cu/XLPE/CWS/PVC
N2XS(SE)Y YJLSV
Al/XLPE/CWS/PVC
N2XS(SE)Y Copper or aluminum conductor XLPE
insulated, Copper wire+ Copper tape
screen PVC sheathed power cable
For laying indoor, tunnel, underground and cannel.
Unable to bear external mechanical pulling force and pressure during laid, fault current requires large.
CWS(Copper wire screen)
type: A: Fixed section
B: Full/one third/one sixth/one eighth/one sixteenth neutral YJSY
Cu/XLPE/CWS/L(M.H)DPE
N2XS(SE)2Y
YJLSY
Al/XLPE/CWS/L(M.H)DPE
N2XS(SE)2Y Copper or aluminum conductor XLPE
insulated, Copper wire+ Copper tape
screen PE/LDPE/HDPE sheathed power cable YJE
Cu/XLPE/CWS/LSOH YJLE
Al/XLPE/CWS/LSOH Copper or aluminum conductor XLPE
Copper wire+ Copper tape
screen LSOH sheathed power cable YJV22
Cu/XLPE/STA/PVC YJLV22
Al/XLPE/STA/PVC Copper or aluminum conductor XLPE
insulated, Copper tape screen, steel tape armored, PVC sheathed power cable
For laying indoor, tunnel, underground and cannel.
Able to bear external mechanical forces, but unable to bear large pulling force. YJV23
Cu/XLPE/STA/L(M.H)PE YJLV23
Al/XLPE/STA/L(M.H)PE Copper or aluminum conductor XLPE
insulated, Copper tape screen, steel tape armored, PE/LDPE/HDPE sheathed power cable WD-YJY23
Cu/XLPE/STA/LSOH WD-YJLY23
Al/XLPE/STA/LSOH Copper or aluminum conductor XLPE insulated, Copper tape screen, steel tape armored, PVC sheathed power cable
YJSV22
Cu/XLPE/CWS/STA/PVC
N2XSEBY YJLSV22
Al/XLPE/CWS/STA/PVC
N2XSEBY Copper or aluminum conductor XLPE insulated,
Copper wire+ Copper tape screen, steel tape armored, PVC sheathed power cable
For laying indoor, tunnel, underground and cannel.
Able to bear external mechanical forces, but unable to bear large pulling force. fault current requires large.
CWS(Copper wire screen)
type: A: Fixed section
TypeDescription Main Application Copper Conductor Aluminum Conductor YJSV23
Cu/XLPE/CWS/STA
L(M.H)PE
N2XSEB2Y YJLSV23
Al/XLPE/CWS/STA
L(M.H)PE
NA2XSEB2Y Copper or aluminum conductor XLPE insulated, copper wire+ copper tape screen, steel tape armored, PE/LDPE/HDPE sheathed power cable For laying indoor, tunnel, underground and canal. Able to bear external mechanical forces, but unable to bear large pulling force. fault current requires large.
CWS(Copper wire screen) tape: Fixed section WD-YJSY23
Cu/XLPE/CWS/STA/LSOH WD-YJLSY23
Al/XLPE/CWS/STA/LSOH Copper or aluminum conductor XLPE insulated, copper wire+ copper tape screen, steel tape armored, LOSH sheathed power cable YJV32
Cu/XLPE/SWA/PVC YJLV32
Al/XLPE/SWA/PVC Copper or aluminum conductor XLPE INSULATED, Copper tape screen, galvanized steel wire armored, PVC sheathed power cable. For laying in shaft, water under ground and large difference of level, able to bear external mechanical pressure and moderate pulling force. YJV33
Cu/XLPE/SWA/L(M.H)PE YJLV33
Al/XLPE/SWA/L(M.H)PE Copper or aluminum conductor XLPE insulated, copper tape screen, galvanized steel wire armored, PE/LDPE/HDPE sheathed power cable WD-YJY33
Cu/XLPE/SWA/LSOH WD-YJLY33
Al/XLPE/SWA/LSOH Copper or aluminum conductor XLPE insulated, copper tape screen, galvanized steel wire armored, LSOH sheathed power cable. YJSV32
Cu/XLPE/CWS/SWA/PVC
N2XSWRY YJLSV32
Al/XLPE/CWS/SWA/PVC
NA2XSWRY Copper or aluminum conductor XLPE insulated, copper wire+ copper tape screen, galvanized steel wire armored, PVC sheathed power cable For laying in shaft, water under ground and large differnce of level, able to bear extenal mechanical pressure and moderate pulling force. fault current requires large.
CWS(Copper wire screen) tape: Fixed section YJSV33
Cu/XLPE/CWS/SWA/L(M.H)PE
N2XSER2Y YJLSV33
Al/XLPE/CWS/SWA/L(M.H)PE
NA2XSER2Y Copper or aluminum conductor XLPE insulated, copper wire+ copper tape screen, galvanized steel wire armored, PE/LDPE/HDPE sheathed power cable WD-YJY33
Cu/XLPE/SWA/LSOH WD-YJLY33
Al/XLPE/SWA/LSOH Copper or aluminum conductor XLPE insulated, copper wire+ copper tape screen, galvanized steel wire armored, LSOH sheathed power cable
4. Scope of voltage grade and core number and cross-section
a) National standardRated voltage(KV)3.6/6 6/6 6/10 8.7/10 8.7/15 12/15 12/20 18/20 18/30 21/35 26/35 Core Number 1 core, 3 core Cross-section
mm2 1C 25~800 35~800 3C 25~400 35~400
b) IEC/BS/DIN standardRated voltage(KV)3.6/6 6/6 6/10 8.7/10 8.7/15 12/15 12/20 18/20 18/30 21/35 26/35 Core Number 1 core, 3 core Cross-section
mm2 1C 25~800 35~800 3C 25~400 35~400
c) ASTM standardRated voltage(KV)5001-8000 8001-15000 15001-25000 25001-28000 28001-35000 35001-46000 1 core, 3 core Cross-section
mm2 1C
6AWG~1600kcmil 2AWG~1600kcmil 1AWG~1600kcmil 2AWG~1600kcmil 1/0AWG~1600kcmil
3C 6AWG~1600kcmil 2AWG~1600kcmil 1AWG~1600kcmil 2AWG~1600kcmil 4/0AWG~1600kcmil
Nominal Cross-section
mm225 35 50 70 95 120 150 185 240 300 20oC DC Resistance
Ω/km Cu 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Al 1.2 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Nominal Cross-section
mm2 400 500 630 800 1000 1200 1400 1600 1800 2000 20oC DC Resistance
Ω/km Cu 0.0470 0.0366 0.0283 0.0221 0.0176 0.0151 0.0123 0.0108 0.0096 0.0086 Al 0.0778 0.0605 0.0469 0.0367 0.0291 0.0247 0.0202 0.0177 0.0157 Nominal Cross-section
AWG 6 5 4 3 2 1 1/0 2/0 3/0 4/0 20oC DC Resistance
Ω/km Cu 1.3219 1.0453 0.8298 0.6594 0.5211 0.4149 0.3281 0.2605 0.2065 0.1640 Al 2.1699 1.7167 1.3631 1.0802 0.8551 0.6783 0.5401 0.4276 0.3376 0.2688 Nominal Cross-section
MCM 250 300 350 400 450 500 550 600 650 700 20oC DC Resistance
Ω/km Cu 0.1386 0.1158 0.0991 0.0865 0.0772 0.0695 0.0630 0.0579 0.0534 0.0495 Al 0.2273 0.1897 0.1623 0.1421 0.1263 0.1138 0.1032 0.0948 0.0874 0.0813 Nominal Cross-section
MCM 750 800 900 1000 1100 1200 1300 1400 1500 1600 20oC DC Resistance
Ω/km Cu 0.0463 0.0434 0.0386 0.0347 0.0316 0.0289 0.0237 0.0248 0.0231 0.0217 Al 0.0759 0.0711 0.0630 0.0569 0.0518 0.0473 0.0437 0.0405 0.0379 0.0357
Production Equipment
Test Equipment
Our Services
Cu/XLPE/PVC
Al/XLPE/PVC
XLPE insulated, Copper tape
screen PVC sheathed power cable
Unable to bear external mechanical pulling force and pressure during laid.
Cu/XLPE/L(H)DPE
Al/XLPE/L(H)DPE
XLPE insulated, Copper tape screen
PE/LDPE/HDPE sheathed power cable
Cu/XLPE/LSOH
Al/XLPE/LSOH
insulated, Copper tape
screen LSOH sheathed power cable
Cu/XLPE/CWS/PVC
N2XS(SE)Y
Al/XLPE/CWS/PVC
N2XS(SE)Y
insulated, Copper wire+ Copper tape
screen PVC sheathed power cable
For laying indoor, tunnel, underground and cannel.
Unable to bear external mechanical pulling force and pressure during laid, fault current requires large.
CWS(Copper wire screen)
type: A: Fixed section
B: Full/one third/one sixth/one eighth/one sixteenth neutral
Cu/XLPE/CWS/L(M.H)DPE
N2XS(SE)2Y
YJLSY
Al/XLPE/CWS/L(M.H)DPE
N2XS(SE)2Y
insulated, Copper wire+ Copper tape
screen PE/LDPE/HDPE sheathed power cable
Cu/XLPE/CWS/LSOH
Al/XLPE/CWS/LSOH
Copper wire+ Copper tape
screen LSOH sheathed power cable
Cu/XLPE/STA/PVC
Al/XLPE/STA/PVC
insulated, Copper tape screen, steel tape armored, PVC sheathed power cable
For laying indoor, tunnel, underground and cannel.
Able to bear external mechanical forces, but unable to bear large pulling force.
Cu/XLPE/STA/L(M.H)PE
Al/XLPE/STA/L(M.H)PE
insulated, Copper tape screen, steel tape armored, PE/LDPE/HDPE sheathed power cable
Cu/XLPE/STA/LSOH
Al/XLPE/STA/LSOH
Cu/XLPE/CWS/STA/PVC
N2XSEBY
Al/XLPE/CWS/STA/PVC
N2XSEBY
Copper wire+ Copper tape screen, steel tape armored, PVC sheathed power cable
For laying indoor, tunnel, underground and cannel.
Able to bear external mechanical forces, but unable to bear large pulling force. fault current requires large.
CWS(Copper wire screen)
type: A: Fixed section
Type
Cu/XLPE/CWS/STA
L(M.H)PE
N2XSEB2Y
Al/XLPE/CWS/STA
L(M.H)PE
NA2XSEB2Y
CWS(Copper wire screen) tape: Fixed section
Cu/XLPE/CWS/STA/LSOH
Al/XLPE/CWS/STA/LSOH
Cu/XLPE/SWA/PVC
Al/XLPE/SWA/PVC
Cu/XLPE/SWA/L(M.H)PE
Al/XLPE/SWA/L(M.H)PE
Cu/XLPE/SWA/LSOH
Al/XLPE/SWA/LSOH
Cu/XLPE/CWS/SWA/PVC
N2XSWRY
Al/XLPE/CWS/SWA/PVC
NA2XSWRY
CWS(Copper wire screen) tape: Fixed section
Cu/XLPE/CWS/SWA/L(M.H)PE
N2XSER2Y
Al/XLPE/CWS/SWA/L(M.H)PE
NA2XSER2Y
Cu/XLPE/SWA/LSOH
Al/XLPE/SWA/LSOH
4. Scope of voltage grade and core number and cross-section
a) National standardRated voltage(KV)
mm2
b) IEC/BS/DIN standardRated voltage(KV)
mm2
c) ASTM standardRated voltage(KV)
mm2
3C
Nominal Cross-section
mm2
Ω/km
mm2
Ω/km
AWG
Ω/km
MCM
Ω/km
MCM
Ω/km
Production EquipmentTest Equipment
Our Services1. Sufficient support for our tendering representatives.
2. Qualification documents support
3. OEM service available based on official & legal authorization.
4. Strict quality control system.
5. Faster lead time than our competitors.
6. Excellent quality with reasonable price.
7. Strong technical support (technical data, drawing, etc.)
8. Cable solutions to your particular requirements.
9. Free sample is available with economic express fee.
10. Factory acceptance test assistant
11. Container loading design and handling
FAQWhy choose us ?
1. Geographical location and convenient transportation, saving transportation costs
2. Full range of products, good reputation.
3. The leading edge technology. Different dedicated engineers and technicians for factory production, domestic sales and foreign sales, service and other jobs.
4. The sophisticated management system and management team. ISO9001,14001 and GB / T28001 passed. Computer management system for sales and production, etc.
5. Advanced service concept and positive attitude.
