Low Voltage Froh2r Cable PVC Insulated PVC Sheathed Multicore Cable

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Industrial Cable
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC

Base Info

  • Model NO.：FROH2R Cable
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemLow Voltage FROH2R PVC CableConductorFine bare copper strandsInsulationPVCShieldPolyester Tape/Bare copper wires braidingOuter SheathPVCCore NumberMulticores (As client's requirement)Rated Voltage 300/500V; 450/750VTest Voltage2000V (300/500V); 2500V (450/750V)Minimum Bending RadiusFlexing: 10 x Ø
Static: 6 x ØTemperature RangeFlexing Temperature: 0ºC to +70 ºC
Static Temperature: -15ºC to +70 ºCColorOptionalApplicationThese cables are suitable for connections and movable equipments where performances and entertainments take place. Can be laid inside, even in dry or wet environments or outside but only for a temperatureorary use. The main feature of these cables is its protection against electromagnetic interference thanks to the copper braid. Can be lay under plaster or directly buried, even if protected, is not allowed.
