8mm2 PVC Insulated Electrical Wire for Philippines Market
Henan Hongda Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Housing
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Material Shape：Round Wire
- Range of Application：Housing
- Certification：ISO9001, CCC
- Brand：Honda
- Color：Red Blue Yellow Green White Black
- Transport Package：in Roll or in Pallent
- Specification：2.5
- Trademark：NO
- Origin：Henan
- HS Code：8544492100
- Production Capacity：10000 M Per Day
Description
Basic Info.
Material Shape Round Wire Range of Application Housing Certification ISO9001, CCC Brand Honda Color Red Blue Yellow Green White Black Transport Package in Roll or in Pallent Specification 2.5 Trademark NO Origin Henan HS Code 8544492100 Production Capacity 10000 M Per DayProduct Description
1.Application:Fixed wiring ,civil power ,mobile equipment
2.Construction
Conductor type:
IEC 60228-2004 class 1 or class 2.
Nominal Cross-section area: 0.5~400mm2
PVC insulation
We can according to our client's need and also provide technical data
3.Characteristic
Rated Voltage:
450/750V More-than 1.5mm2 single core conductor
300/500V Less-than 1.5mm2 single core and multicore conductor
300/300VLess-than 1.5mm2 multicore conductor
Test Voltage:
AC 1500V/5Min for 0.5~1mm2 multicore conductor
AC 2000V/5Min for 0.5~1mm2 single core and multicore conductor
AC 2500V/5Min Other.
Color of Insulation:
Red,Yellow,Green,Light blue,White,Black,Grey,Brown,Orange,Violet,Yellow/Green.
4.Standard
IEC 60227-2007 UL
