Machinery Soft Silicne Rubber Insulated Lead Cable
Jiangyin Yuanda Electrical Material Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground
- Conductor Material：Tinned Copper
- Insulation Material：Silicone Rubber
- Material Shape：Round Wire
Base Info
- Model NO.：JG500
- Range of Application：Lead Wire for Winding of Electrical Machinery
- Certification：ISO9001, UL, CCC, RoHS, VDE, CSA
- Brand：Yuanda
- Nominal Voltage：500V
- Transport Package：Pallet,Carton,Tray,Reel
- Specification：0.5-10mm2
- Trademark：Yuanda
- Origin：Wuxi, China
- HS Code：8544492100
- Production Capacity：1000km,Day
Description
500VSection
mm2 Conductor
Construction
No./D(mm) Diameter
(mm) Thickness
(mm) Nominal outer diameter
(mm) Max outer
diameter
(mm) Cu core Tinned-Cu core 0.5 28/0.15 0.93 0.8 2.53 3.0 39.0 40.1 0.75 24/0.20 1.14 0.8 2.74 3.2 26.0 26.7 1 32/0.20 1.32 0.8 2.92 3.4 19.5 20.0 1.5 30/0.25 1.6 0.8 3.2 3.7 13.3 13.7 2.5 49/0.25 2.0 0.9 3.8 4.4 7.98 8.21 4 56/0.30 2.7 1.0 4.7 5.2 4.95 5.09 6 84/0.40 3.4 1.0 5.4 6.1 3.30 3.39 10 84/0.40 4.2 1.2 6.6 7.6 1.91 1.95
mm2
Construction
No./D(mm)
(mm)
(mm)
(mm)
diameter
(mm)
