Low Voltage Copper Conductor Copper Wire Braiding Instrument Cable
YIFANG ELECTRIC GROUP INC.- Application：Telecommunication, Computer
- Voltage：Low and Medium Voltage Cable
- Insulation Material：XLPE
- Sheath Material：PVC or PE
- Material Shape：Round Wire
- Wire Core Material：Red Copper Wire
Base Info
- Certification：ISO, CCC, CE
- Brand：Yifang
- Armour：Steel Wire or Steel Tape
- Transport Package：Wooden Drum, Steel Drum or Steel-Wooden Drum etc.
- Trademark：Yifang
- Origin：China
- HS Code：8544601200
- Production Capacity：50, 000km Per Year
Description
Basic Info.
Certification ISO, CCC, CE Brand Yifang Armour Steel Wire or Steel Tape Transport Package Wooden Drum, Steel Drum or Steel-Wooden Drum etc. Trademark Yifang Origin China HS Code 8544601200 Production Capacity 50, 000km Per YearProduct Description
Low Voltage Copper Conductor Copper Wire Braiding Instrument CableApplication:
Mainly used in the computer network and control systems, as the connection wires. Capacity of resisting disturbance is relatively strong
Applicable Standards: BS 5308, IEC60502
Production Scope:
Voltage: 1KV or below
Conductor type: Stranded or solid (class 1 or 2)
Nominal Cross Section Area: 0.5mm2 to 6mm2
Pair No.: 1-61pairs
Construction:
Conductor: Copper or tinned copper
Insulation: PVC /PE /XLPE
Individual Screen (optional):
Aluminum foil with drain wire, Copper wire braiding, Copper tape
Overall Screen: Aluminum foil with drain wire, Copper wire braiding, Copper tape
Armor (optional): Steel Tape / Steel Wire
Sheath: PVC, PE, LSHF, or other special requirements
Core's Color:
One Pair: Black/White Pair
Two Pairs and above: black/White Pairs with Numbers 1, 2….n or color.
Color of Sheath: Black, blue or customer designated
* We can design and produce according to client's requirement.
Certificates:
Pictures of our workshop:
