Nyy H07rnf/H05rn-F/H05rr-F Rubber Cabtyre Flexible Electrical Wire High Quality Price Flexible Rubber Wire Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Class 5 Flexible Copper Conductor
- Application：Heating, Underground
- Conductor Material：Copper
- Sheath Material：Pcp (Polychloroprene)
- Insulation Material：Epr (Ethylene Propylene Rubber)
Base Info
- Model NO.：H07RNF
- Material Shape：Round Wire
- Range of Application：Heavy Equipment, Machine Tools, Agricultural etc.
- Certification：ISO9001, CE, CCC
- Brand：Fengda
- Color：Customized
- OEM / ODM：Available
- Whether Quality Inspection：Provide Inspection Certificate
- Whether It Is Environmentally Friendly：Yes
- Standard：Customized Based on Specified National Standard
- Core：Single Core and Multicore
- Transport Package：Drum , Roll
- Specification：International General Specifications
- Trademark：FengDa
- Origin：China
- HS Code：854449210
- Production Capacity：5000000 Km , Year
Description
Flexible Rubber Insulated Cable
Application:
H07RN-F flexible rubber cable is a heavy-duty rubber sheathed cable for use on heavy equipment, such as machine tools and agricultural machinery, cabel h07rn-f is exposed to high stress in dry and damp rooms as well as outdoors and in damp industrial environments. Constant, operational movements, the use of these cables in moving cable carriers, respectively on motor drum guides or a stress of more than 15 N/mm² is not permitted.
Standard:
EN 50525-2-21, EN 60228
Flame Retardant according toIEC/EN60332-1-2
Conductor: Class 5 flexible copper conductor
Insulation: EPR (Ethylene Propylene Rubber)
Sheath: PCP (Polychloroprene)
Voltage Rating (Uo/U): 450/750V
Temperature Rating :
Fixed: -30°C to +60°C
Fixed protected installations: +85°C
Flexed: -15°C to +60°C
Minimum Bending Radius:
Fixed: 4 x overall diameter
Flexed: 6 x overall diameter
H07RN-F Single Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 1x1.5 | 30/0.25 | 0.8 | 6 | 49 |
| 1x 2.5 | 50/0.25 | 0.9 | 6.6 | 63 |
| 1x4 | 56/0.30 | 1 | 7.6 | 92 |
| 1x6 | 84/0.30 | 1 | 8.3 | 115 |
| 1x10 | 80/0.40 | 1.2 | 10.7 | 189 |
| 1x16 | 126/0.40 | 1.2 | 12 | 260 |
| 1x25 | 196/0.40 | 1.4 | 14.1 | 369 |
| 1x35 | 276/0.40 | 1.4 | 15.8 | 500 |
| 1x50 | 396/0.40 | 1.6 | 18.3 | 689 |
| 1x70 | 360/0.50 | 1.6 | 20.7 | 918 |
| 1x95 | 475/0.50 | 1.8 | 23.4 | 1202 |
| 1x120 | 608/0.50 | 1.8 | 25.6 | 1489 |
| 1x150 | 756/0.50 | 2 | 28.3 | 1824 |
| 1x185 | 925/0.50 | 2.2 | 31 | 2202 |
| 1x240 | 1221/0.50 | 2.4 | 34.5 | 2847 |
| 1x300 | 1525/0.50 | 2.6 | 37.7 | 3495 |
| 1x400 | 2013/0.50 | 2.8 | 37.7 | 3495 |
| 1x500 | 1769/0.60 | 3 | 37.7 | 3495 |
| 1x630 | 2257/0.60 | 3 | 37.7 | 3495 |
H07RN-F 2 Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 2 X 1.0 | 32/0.20 | 0.8 | 8.4 | 98 |
| 2 X 1.5 | 30/0.50 | 0.8 | 9.4 | 116 |
| 2 X 2.5 | 50/0.25 | 0.9 | 11 | 164 |
| 2 X 4.0 | 56/0.30 | 1 | 12.8 | 232 |
| 2 X 6.0 | 84/0.30 | 1 | 14.2 | 297 |
| 2 X 10.0 | 80/0.40 | 1.2 | 20.4 | 573 |
| 2 X 16.0 | 126/0.40 | 1.2 | 23 | 774 |
| 2 X 25.0 | 196/0.40 | 1.4 | 27.4 | 1110 |
| 2 X 35.0 | 276/0.40 | 1.4 | 30.8 | 1474 |
H07RN-F 3 Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 3 X 1.0 | 32/0.20 | 0.8 | 9 | 108 |
| 3 X 1.5 | 30/0.50 | 0.8 | 10.3 | 141 |
| 3 X 2.5 | 50/0.25 | 0.9 | 11.8 | 200 |
| 3 X 4.0 | 56/0.30 | 1 | 13.7 | 285 |
| 3 X 6.0 | 84/0.30 | 1 | 15.2 | 371 |
| 3 X 10.0 | 80/0.40 | 1.2 | 21.9 | 712 |
| 3 X 16.0 | 126/0.40 | 1.2 | 24.7 | 971 |
| 3 X 25.0 | 196/0.40 | 1.4 | 29.4 | 1394 |
H07RN-F 4 Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 4 X 1.0 | 32/0.20 | 0.8 | 10 | 134 |
| 4 X 1.5 | 30/0.25 | 0.8 | 11.2 | 174 |
| 4 X 2.5 | 50/0.25 | 0.9 | 12.6 | 249 |
| 4 X 4.0 | 56/0.30 | 1 | 15.1 | 361 |
| 4 X 6.0 | 84/0.30 | 1 | 16.9 | 480 |
| 4 X 10.0 | 80/0.40 | 1.2 | 24 | 890 |
| 4 X 16.0 | 126/0.40 | 1.2 | 27 | 1225 |
| 4 X 25.0 | 196/0.40 | 1.4 | 32.6 | 1792 |
| 4 X 35.0 | 276/0.4 | 1.4 | 36.5 | 2380 |
| 4 X 50.0 | 396/0.4 | 1.6 | 42 | 3635 |
| 4 X 70.0 | 360/0.5 | 1.6 | 49 | 4830 |
| 4 X 95.0 | 475/0.5 | 1.8 | 55 | 6320 |
H07RN-F 5 Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 5 X 1.0 | 32/0.20 | 0.8 | 11 | 170 |
| 5 X 1.5 | 30/0.50 | 0.8 | 12.3 | 218 |
| 5 X 2.5 | 50/0.25 | 0.9 | 14.5 | 309 |
| 5 X 4.0 | 56/0.30 | 1 | 16.9 | 450 |
| 5 X 6.0 | 84/0.30 | 1 | 18.8 | 595 |
| 5 X 10.0 | 80/0.40 | 1.2 | 26.5 | 1100 |
| 5 X 16.0 | 126/0.40 | 1.2 | 30 | 1528 |
| 5 X 25.0 | 196/0.40 | 1.4 | 36 | 2200 |
| 5 X 35.0 | 276/0.40 | 1.4 | 40 | 2925 |
H07RN-F Multicore Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 7 X 1.5 | 30/0.50 | 0.8 | 14.6 | 295 |
| 7 X 2.5 | 50/0.25 | 0.9 | 16.6 | 410 |
| 12 X 1.5 | 30/0.50 | 0.8 | 18.9 | 500 |
| 12 X 2.5 | 50/0.25 | 0.9 | 22 | 720 |
| 19 X 1.5 | 30/0.50 | 0.8 | 22.5 | 715 |
| 19 X 2.5 | 50/0.25 | 0.9 | 26 | 1030 |
| 24 X 1.5 | 30/0.50 | 0.8 | 25 | 900 |
| 24 X 2.5 | 50/0.25 | 0.9 | 29 | 1350 |
| 27 X 1.5 | 30/0.50 | 0.8 | 29 | 1100 |
| 27 X 2.5 | 50/0.25 | 0.9 | 33 | 1521 |
| 37 X 1.5 | 30/0.50 | 0.8 | 29.8 | 1300 |
| 37 X 2.5 | 50/0.25 | 0.9 | 36 | 1900 |
