• Model NO.：Hook up wire
• Range of Application：Connected with The Motor Winding
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE
• Brand：Fengda
• Transport Package：Wooden Box Packing or Pallet Shipping Containers
• Specification：US $0.5-5, Meter
• Trademark：FengDa
• Origin：Tianjin, China
• HS Code：8544492100
• Production Capacity：5, 000, 000km,Year



Rated voltage: 600V,Rated temperature:150ºC



Tinned or bare, stranded or solid copper conductor, 30AWG -750KCmin.



XLPE(irradiated) insulation





Passes UL VW-1 & CSA FT1 vertical flame test   Uniform insulation thickness of wire to ensure easy stripping and cutting  Resistant to heat, cold, oils and chemicals,conforming RoHS







Conductor Type

Conductor

Insulation

 Max Resistance at 20ºC

20ºC
Max Insulation
Resistance
at 20ºC



Dielectric
Strength
AC 1 min

Standard
Length



Spec

/

 Dia

Nom.

 Thick.


Nom.

 Dia.

AWGNo./mmmmmmmmΩ/KmMΩ.KmVFt(M)



Stranded Conductor

307/0.100.300.761.883811520002000(610)287/0.1270.381.96239267/0.160.482.061502411/0.160.612.1994.22217/0.160.7623559.42026/0.160.942.5036.71841/0.161.182.7623.21000(305)1626/0.2541.493.0514.61441/0.2541.883.458.961265/0.2542.374.005.6410105/0.2543.405.003.5461049/0.373.385.003.546
