Hfp56 Copper Enclosed Insulated Conductor Rail Current Collector
Hangzhou Nante Machinery Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：COLLECTOR
- Certification：ISO9001, CE
- Brand：Nante
- Transport Package：Cartons
- Specification：35A to 80A
- Trademark：NANTE
- Origin：China
- HS Code：843149
- Production Capacity：10, 000PCS,Month
Description
Model
Pole No.
Cross section
Max. current
Leakage-distance
Max. voltage
Resistance
Dimensions (H * W)
Weight
HFP56-4-8/35
4
8
35
35
600
1.944
73*56
2.09
HFP56-4-10/50
4
10
50
35
600
1.656
73*56
2.16
HFP56-4-12/65
4
12
65
35
600
1.321
73*56
2.23
HFP56-4-15/80
4
15
80
35
600
1.137
73*56
2.3
HFP56-4-20/100
4
20
100
33
600
1.011
73*56
2.43
HFP56-4-25/120
4
25
120
33
600
0.713
73*56
2.56
HFP56-4-35/140
4
35
140
33
600
0.522
73*56
2.95
HFP56-4-50/170
4
50
170
33
600
0.337
73*56
3.25
HFP56-4-70/210
4
70
210
33
600
0.265
73*56
3.85
HFP56-4-80/240
4
80
240
30
600
0.223
73*56
4.16
HFP56-3-10/50
3
10
50
45
600
1.656
73*56
1.95
HFP56-3-15/80
3
15
80
45
600
1.137
73*56
2.13
HFP56-3-20/100
3
20
100
45
600
1.011
73*56
2.24
HFP56-3-25/120
3
25
120
45
600
0.713
73*56
2.37
HFP56-3-35/140
3
35
140
45
600
0.522
73*56
2.63
HFP56-3-50/170
3
50
170
45
600
0.337
73*56
3.02
HFP Series Multiple-Poles Conductor Rail System
Max. voltage
600v
Bending strength
75N/mm²±10%
Dielectric strength
30-40kv/mm
Tensile strength
40N/mm²±10%
Special resistance
5×10 Class B1-no flaming particles, self-extinguishing
Permissible Ambient temperature
Standard insulation -30°C- +70°C|High temperature insulation -20°C- +115°C|Low temperature insulation -40°C- +80°C
