Sc/APC Sc/Upc Patchcord G657A1/G657A2 Sm FTTH Flat Fiber Optic/Optical Drop Wire Cable

TOPNET (SHENZHEN) COMMUNICATION CO.,LTD
  • Application：Communication
  • Type：Single-mode Fiber
  • Connection Structure：SC
  • Material Shape：Flat Wire
  • Allowed Lateral Pressure：100(N,100mm)<1000(N,100mm)
  • Allowed Tensile Strength：100N<1000N

Base Info

  • Model NO.：GJYXCH
  • Core：Single Core
  • Certification：RoHS, UL, CE
  • Brand：OEM
  • Sheath Material：LSZH
  • Fiber Type Sm：G652D,G657A1,G657A2,G657b3
  • Fiber Type mm：Om1, Om2, Om3, Om4, Om5
  • Cord Number：1-12 Cores
  • Transport Package：Wooden Drum
  • Specification：2.0*3.0mm,2.0*5.0mm
  • Trademark：Topnet
  • Origin：China
  • HS Code：8544700000
  • Production Capacity：8000km Per Month

Description

CharacteristicSM , MMConnector type FC/SC/ST/LC/MU/MT-RJ/ESCON/E2000Diameter(mm) 2.0*3.0/2.0*5.0Polishing grade SM UPCMM UPCSM APCInsertion loss Grade B≤0.15dB≤0.1dB≤0.15dBGrade C≤0.30dB≤0.30dB≤0.30dBReturn loss ≥55dB≥30dB≥65dBInterchangeability≤0.1dBRepeatability ≤0.1dBOperation temperature (ºC)-20°C ~ +70°CStorage temperature (ºC)-40°C ~ +80°CConnector 1SU: SC/UPCSA: SC/APCLU: LC/UPCLA: LC/APCFU: FC/UPCFA: FC/APCTU: ST/UPCTA: ST/APCEU: E2000/UPCEA: E2000/APC, etc.Connector 2SU: SC/UPCSA: SC/APCLU: LC/UPCLA: LC/APCFU: FC/UPCFA: FC/APCTU: ST/UPCTA: ST/APCEU: E2000/UPCEA: E2000/APC, etc.Fiber CountSI: SimplexFiber Type2D: SM G.652D (standard)7A1: SM G.657A17A2: SM G.657A2OM1: MM 62.5/125umOM2: MM 50/125umOM3: MM 50/125umOM4: MM 50/125umOM5: MM 50/125umCable Length1: 1m (standard)1.5: 1.5m2: 2m, etcCable Diameter2: 2.0mm3: 3.0mm (standard)Jacket MaterialL: LSZH

Package
Sc/APC Sc/Upc Patchcord G657A1/G657A2 Sm FTTH Flat Fiber Optic/Optical Drop Wire CableSc/APC Sc/Upc Patchcord G657A1/G657A2 Sm FTTH Flat Fiber Optic/Optical Drop Wire CableSc/APC Sc/Upc Patchcord G657A1/G657A2 Sm FTTH Flat Fiber Optic/Optical Drop Wire Cable
