• Model NO.：XGT-200A
• Transport Package：Carton
• Specification：282*186*75mm
• Trademark：ShowRange
• Origin：Shanghai
• HS Code：9025800000
• Production Capacity：500PCS,Month

Optical Interface Two GigE Ports1000Base-SX1000Base-LX1000Base-ZXWavelength (nm)85013101550Laser/Connector/Transceivers typeVCSEL/ LC/ SFPFP/ LC/ SFPDFB/ LC/ SFPElectrical InterfacesTwo Ports:10/100BaseT Half/Full Duplex and 1000BaseT Full  Duplex, Choose straight or crossover cables10BaseT100BaseT1000BaseTConnectorRJ-45RJ-45RJ-45SFP+ Optical Interface (10G)Two 10GigE Ports10GBase-SR/ SW10GBase-LR/ LW10GBase-ER/ EWWavelength (nm)85013101550Laser/Connector/Transceivers typeVCSEL/ LC/ SFP+DFB/ LC/ SFP+CML/ LC/ SFP+Testing ItemsY.1564Capability to perform the service configuration test and service performance test as per ITU-T Y.1564. Tests can be performed to loopback or /dual test set mode for bidirectional results.RFC2544BERT Bit Error TestUp to layer 4 supported with or without VLAN Q-in-Q.Through modeSectionalize traffic between a service provider's network and customer premises equipment.Service Disruption Time (SDT)Disruption time statistics include shortest, longest, last, average, total and pass/fail thresholds.Multi-stream GenerationCapability to transmit and monitor up to 16 streams of Ethernet and IP traffic.Traffic Generation and MonitoringCapability to generate and monitor Traffic of Ethernet and IP; Traffic shaping can be based on those statistics: throughput, frame loss, packet jitter, frame sorting, latency, frame size, traffic type and traffic monitoringVLAN StackingCapability to generate streams with up to two layers of VLAN (including IEEE802.1ad Q-in-Q tagged VLAN) and to filter received traffic by VLAN ID or VLAN priority at any of the stacked VLAN layers. IPv6 TestIncluding BERT, RFC2544, Traffic generation and monitoring, Background traffic, Smart Loopback, Ping and trace routeGeneral Specifications

Display	7 inch color TFT touch screen (Resolution 960×480)
Data storage	8GB
Interface	USB 2.0 port, RJ-45 LAN
Battery	Rechargeable Lithium battery,4 hours continuous operation
Power Supply	AC/DC Adapter; Input 100 - 240V AC,50/60Hz,2A(Max.); Output 24V DC 90W
Dimension	282×186×75mm
Weight	2.9Kg

Order Information
Model:
XGT-200A: Two full function 10G test port, and 10G test port can make a punch through testing
Standard Package
XGT-200A Host, Battery, AC Adapter, Software CD, Carrying Case, User Manual, Warranty card
Optional:
CAT6 RJ-45 Gigabit Ethernet Cable
LC-LC Duplex Patchcord
10G SFP+ Optical Module (Wavelength/Transmission Distance:850nm/550m,1310nm/10km,1550nm/40km)
1.25G SFP Optical Module (Wavelength/Transmission Distance:850nm/550m,1310nm/10km)
OAM Test Function Module
Notice: According to the specific requirements, the specification of Optical Module can be changed.
