14AWG Chromel Alumel Thermocouple Wire 1.63mm With Bright Surface
Shanghai Tankii Alloy Material Co., Ltd.- Type：Insulated
- Conductor Type：Solid
- Application：Heating
- Conductor Material：NiCr-NiSi
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：K
- Material Shape：Round Wire
- Range of Application：heating
- Certification：ISO9001, RoHS
- Brand：Tankii
- Dia：0.3,0.5,0.8,1.0,1.2,1.6,2.0,2.5,3.2mmm
- Surface：Bright, oxidized
- Grade：I,II,III
- Tensile strength：more than 390
- Transport Package：100m,Spool
- Specification：0.3,0.5,0.8,1.0,1.2,1.6,2.0,2.5,3.2mm
- Trademark：TANKII
- Origin：Shanghai, China
- HS Code：7505220000
- Production Capacity：1000 Tons,Year
Description
Conductor Name
Polarity
Code
Nominal Chemical Composition /%
Ni
Cr
Si
Ni-Cr
Positive
KP
90
10
--
Ni- Si
Negative
KN
97
--
3
14AWG Chromel Alumel Thermocouple Wire 1.63mm With Bright SurfaceWorking Temperature
Diameter/mm
Long time Working temperature /ºC
Short period Working temperature /ºC
0.3
700
800
0.5
800
900
0.8,1.0
900
1000
1.2,1.6
1000
1100
2.0,2.5
1100
1200
3.2
1200
1300
