UL1332/1333 Fluoroplastic Insulated Wire
Jiangyin Yuanda Electrical Material Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground
- Conductor Material：Copper
- Insulation Material：Fluoroplastic
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
Base Info
- Model NO.：UL1332,1333
- Transport Package：Pallet,Tray,Carton,Reel
- Specification：CE, RoHS, ISO9001, VDE, CCC
- Trademark：Yuanda
- Origin：Wuxi, Jiangsu, China
- Production Capacity：1000 Km,Day
Description
ConductorInsulation Electrical characteristic Spec
AWG Conductor
construction
No./ φmm Diameter
(mm) Insulation
thickness
(mm) Over outer
diameter
(mm) Resistance
20ºC
Ω/km Permissible
ampactity
20ºC-AMR 30 1×0.25 0.25 0.20 0.65 376.13 0.66 28 1×0.31 0.31 0.25 0.81 227.39 1.05 26 7×0.15 0.46 0.30 1.06 148.94 1.61 19×0.10 0.50 0.30 1.10 148.94 1.61 24 7×0.20 0.61 0.30 1.21 93.25 2.57 19×0.12 0.60 0.30 1.20 93.25 2.57 22 7×0.25 0.76 0.30 1.36 55.00 4.36 19×0.15 0.76 0.30 1.36 55.00 4.36 20 7×0.31 0.95 0.30 1.55 34.60 6.94 19×0.19 0.96 0.30 1.56 34.60 6.94 18 7×0.39 1.19 0.30 1.79 21.80 11.01 19×0.235 1.18 0.30 1.78 21.80 11.01 16 7×0.50 1.53 0.30 2.13 13.70 17.52 19×0.30 1.51 0.30 2.11 13.70 17.52 14 19×0.37 1.86 0.35 2.56 8.62 27.84 12 19×0.46 2.32 0.35 3.02 5.43 44.20 10 37×0.43 3.02 0.35 3.72 3.41 70.38
AWG
construction
No./ φmm
(mm)
thickness
(mm)
diameter
(mm)
20ºC
Ω/km
ampactity
20ºC-AMR
