AWG 6-1000 High Voltage Overhead Bare Conductor AAAC 250mcm

Henan Hongda Cable Co., Ltd.
  • Type：Bare
  • Conductor Type：Stranded
  • Application：Overhead
  • Conductor Material：Aluminum
  • Sheath Material：Bare
  • Insulation Material：Bare

Base Info

  • Model NO.：AWG 6-1000
  • Material Shape：Round Wire
  • Range of Application：Overhead Cable
  • Certification：ISO9001, CE, CCC
  • Conductor：Al,Alloy
  • Manufacture：Yes
  • Quality Guarantee：5 Years
  • Color：Bare
  • Standard：BS IEC Ved NFC
  • Sample：Yes
  • Transport Package：Wooden and Steel Wooden Drum
  • Specification：as customer size
  • Trademark：hongda
  • Origin：Henan
  • HS Code：8544492100
  • Production Capacity：50000km,Months

Description

   Concentric lay stranded Aluminum Alloy Conductor (AAAC), is made out of high strength Aluminum-Magnesium-Silicon Alloy. TBEA manufactures and supply AAAC with different variants of electrical grade alloy type 6101 and 6201.
These conductors are designed to get better strength-to-weight ratio and offer improved electrical properties, excellent sag-tension characteristics, and superior corrosion resistanceCode WordSize - AWG or MCMNominal Cross Sectional AreaNominal Weight kg/kmPhlox3/084.91mm2234.4 Canna397.5202.1mm255.4Arbutius795402.9mm21110.6Jessanine1750885.8mm22445.1

AAAC cable dimension examples

Code WordSize - KCMNominal Cross Sectional AreaNominal Weight kg/kmAkron30.580.610mm2503.49Butte312.86.238mm24989.52Flint740.819.863mm213834.57

ACSR cable dimension examples

Code WordSize - AWG - MCMNominal Cross Sectional AreaNominal Weight kg/kmSwannate426.47mm292.3Linnet336.4198.4mm2689Bittern1272489.1mm22134.1



Cables sizes are available as AWG in cmill, kcmill and MCM.


Packaging&Delivery.
 AWG 6-1000 High Voltage Overhead Bare Conductor AAAC 250mcm
AWG 6-1000 High Voltage Overhead Bare Conductor AAAC 250mcm


Packaging Details:Wooden drums,steel wooden drums or as your requirement
Delivery Time:Normally within 30 days(detailly depend on the order quantity)
