ABC Aerial Bundled Cable Duplex Cable Triplex Cable Quadruplex Cable
Luoyang Sanwu Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Aluminum
- Sheath Material：Non
- Insulation Material：XLPE
Base Info
- Model NO.：ABC-Dayuan-026
- Material Shape：Round Wire
- Range of Application：Overhead Transmision
- Certification：ISO9001, CE, CCC
- Brand：Dayuan
- Quality Check：All Products Checked by Experienced QC
- Trail Order：Welcome
- OEM Service：Welcome
- Delivery Date：15days~35days After Order Confirmed
- Other：High Voltage
- Conductor Shape：Circular Core or Compact Core
- Cross Section Area：1.5-800 mm2
- Standard：IEC502, BS7870-5, GB12527-91
- Key Word：Triplex Cable
- Transport Package：Use The Drum, We Can Make as Customer Requirement
- Specification：IEC, ASTM, ICEA, BS, DIN
- Trademark：Luoyang Dayuan
- Origin：Luoyang, China
- HS Code：85444929
- Production Capacity：100000m,Day
Description
codeRated Voltage Type ABC
AWG or kcmilStructure Neutral Wire (ACSR) Phase Wire Cable Cable Steel Aluminium Conductor Aluminium Dia Dia Dia kg/km No. Dia No. Dia Dia No. Dia mm Morochuca 3*6AWG+1*6AWG 1 1.68 6 1.68 5.04 1 4.11 4.11 1.14 6.40 14.62 221 Chola 3*6AWG+1*6AWG 1 1.68 6 1.68 5.04 7 1.55 4.66 1.14 6.95 15.62 227 Morgan 3*4AWG+1*4AWG 1 2.12 6 2.12 6.36 1 5.19 5.19 1.14 7.48 17.37 331 Hackney 3*4AWG+1*4AWG 1 2.12 6 2.12 6.36 7 1.96 5.88 1.14 8.17 18.62 338 Palomino 3*2AWG+1*2AWG 1 2.67 6 2.67 8.02 7 2.47 7.42 1.14 9.71 22.41 511 Costena 3*1/0AWG+1*1/0AWG 1 3.37 6 3.37 10.11 19 1.89 9.47 1.52 12.52 28.77 824 Grullo 3*2/0AWG+1*2/0AWG 1 3.78 6 3.78 11.35 19 2.13 10.63 1.52 13.68 31.61 1015 Suffolk 3*3/0AWG+1*3/0AWG 1 4.25 6 4.25 12.74 19 2.39 11.94 1.52 14.99 34.82 1254 Appaloosa 3*4/0AWG+1*4/0AWG 1 4.77 6 4.77 14.31 19 2.68 13.40 1.52 16.45 38.42 1554 Broneo 3*336.4+1*336.4 1 3.47 18 3.47 17.36 19 3.38 16.90 2.03 20.96 48.43 2321 Gelding 3*336.4+1*4/0AWG 1 4.77 6 4.77 14.31 19 3.38 16.90 2.03 20.96 46.59 2221
