• Model NO.：aacsr
• Wire Core Material：Aluminum
• Certification：ISO, CE, SABS
• Model：Aacsr
• Brand：Jiapu
• Capacity：2000ton,Month
• Min.Order Qty：1km
• Delivery Length：Accord with The Request
• Certificate：SABS, ISO9001-2008, CQC Certificate, CE , SGS
• Port of Loading：Tianjin, Qingdao, Ningbo, Shanghai, Xiamen
• Payment Term：L,C, D,P, D,a ,T,T, M,T, D,D, O,a, C.W.O, C.O.D, C
• Transport Package：Drum
• Trademark：Jiapu
• Origin：Zhengzhou
• Production Capacity：2000ton,Month

Basic Info.

Model NO. aacsr Wire Core Material Aluminum Certification ISO, CE, SABS Model Aacsr Brand Jiapu Capacity 2000ton/Month Min.Order Qty 1km Delivery Length Accord with The Request Certificate SABS, ISO9001-2008, CQC Certificate, CE , SGS Port of Loading Tianjin, Qingdao, Ningbo, Shanghai, Xiamen Payment Term L/C, D/P, D/a ,T/T, M/T, D/D, O/a, C.W.O, C.O.D, C Transport Package Drum Trademark Jiapu Origin Zhengzhou Production Capacity 2000ton/Month

Product Description

Application
The AACSR conductors are also suitable for use in all practical transmission towers, and other structures. Application range from extra high voltage(EHV) transmission lines to sub-service spans at distribution or utilization voltages on private premises as like as ACSR.
AACSR(Aluminum Alloy Conductor Steel Reinforced) has also a long service record because of its economy, dependability, and strength to weight ratio. The combined light weight and high conductivity of aluminum with strength of the steel cores enable higher tensions, less sag, and longer spans than any alternative as like as ACSR.
Compared with ACSR, the tensile strength of aluminum conductor is more strong.

Construction
Aluminum Alloy 6201 wires and the steel cores are concentrically stranded and wrapped helically around a central wire. The additional corrosion protection is available through the application of grease to the cores or infusion of the complete cable with grease.

Standard of Production

ASTM B711 Standard, refer to the following specification
B 398 Aluminum Alloy 6201-T81 Wire for Electrical Purpose
B 711 Concentric-lay-stranded Conductor, Aluminum Alloy Steel Reinforced(AACSR)
B 341 Aluminum Coated Steel Core Wire for Aluminum Conductor Steel Reinforced(ACSR/AW)
B 498 Zinc-coated Steel Core Wire for Aluminum Conductor Steel Reinforced (ACSR/AZ)
B 500 Zinc Coated and Aluminum Coated Stranded Steel Core for Aluminum Conductor Steel
Reinforced (ACSR)
2. DIN 48206 Standard
3. IEC 61089 Standard
4. Other International Standard

Nominal Cross Section	Cross Section of Steel Wires	Cross Section of Alloy Wires	Number of Alloy Wires	Diameter of Alloy Wires	Number of Steel Wires	Diameter of Steel Wires	Overall Diameter	Linear Mass	Rated Tensile Strength	Max.D.C. Resistance
mm2	mm2	mm2	-	mm	-	mm	mm	kg/km	daN	Ω/km
16/2.5	15.27	2.54	6	1.8	1	1.8	5.4	62	748	2.18
25/4	23.86	3.98	6	2.25	1	2.25	6.8	97	1171	1.3952
35/6	34.35	5.73	6	2.7	1	2.7	8.1	140	1685	0.9689
44/32	43.98	31.67	14	2	7	2.4	11.2	373	5027	0.7625
50/8	48.25	8.04	6	3.2	1	3.2	9.6	196	2366	0.6898
50/30	51.17	29.85	12	2.33	7	2.33	11.7	378	5024	0.6547
70/12	69.89	11.4	26	1.85	7	1.44	11.7	284	3399	0.4791
95/15	94.39	15.33	26	2.15	7	1.67	13.6	383	4582	0.3547
95/55	96.51	56.3	12	3.2	7	3.2	16	714	9475	0.3471
105/75	105.67	75.55	14	3.1	19	2.25	17.5	899	12014	0.3174
120/20	121.57	19.85	26	2.44	7	1.9	15.5	494	5914	0.2754
120/70	122.15	71.25	12	3.6	7	3.6	18	904	11912	0.2742
125/30	127.92	29.85	30	2.33	7	2.33	16.3	590	7280	0.2621
150/25	148.86	24.25	26	2.7	7	2.1	17.1	604	7236	0.2249
170/40	171.77	40.08	30	2.7	7	2.7	18.9	794	9775	0.1952
185/30	183.78	29.85	26	3	7	2.33	19	744	8922	0.1822
210/35	209.1	34.09	26	3.2	7	2.49	20.3	848	10167	0.1601
210/50	212.06	49.48	30	3	7	3	21	979	12068	0.1581
230/30	230.91	29.85	24	3.5	7	2.33	21	674	10306	0.1449
240/40	243.05	39.49	26	3.45	7	2.68	21.8	985	11802	0.1378
265/35	263.66	34.09	24	3.74	7	2.49	22.4	998	11771	0.1269
300/50	304.26	49.48	26	3.86	7	3	24.5	1233	14779	0.1101
305/40	304.62	39.49	54	2.68	7	2.68	24.1	1155	13612	0.1101
340/30	339.29	29.85	48	3	7	2.33	25	1174	13494	0.0988
380/50	381.7	49.48	54	3	7	3	27	1448	17056	0.0879
385/35	386.04	34.09	48	3.2	7	2.49	26.7	1336	15369	0.0868
435/55	434.29	56.3	54	3.2	7	3.2	28.8	1647	19406	0.0772
450/40	448.71	39.49	48	3.45	7	2.68	28.7	1553	17848	0.0747
490/65	490.28	63.55	54	3.4	7	3.4	30.6	1860	21907	0.0684
550/70	549.65	71.25	54	3.6	7	3.6	32.4	2085	24560	0.061
560/50	561.7	49.48	48	3.86	7	3	32.2	1943	22348	0.0597
680/85	678.58	85.95	54	4	19	2.4	36	2564	30084	0.0494
