• Model NO.：6181y cable
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE
• Model：6181y Cable
• Brand：OEM
• Ralted Voltage：450,750, 0.6,1kv
• Transport Package：Wooden Drum
• Specification：1.5mm2 to 400mm2
• Trademark：OEM
• Origin：China(Mainland)
• HS Code：8544492100
• Production Capacity：500 Kilometer,Month

Working voltage1.0mm^2 to 35mm^2 - 300/500V to BS 6004 50mm^2 and above - 600/1000V to BS 6346Minimum bending radiusup to 35 mm^2 : 3xoverall diameter 50mm^2 to 185mm^2above: 4xoverall diameter 240mm^2 and above: 6xoverall diameterOperating temperature-15 oC to +70 oCInsulation resistance10 MΩxkmFlame retardantIEC 60332.1

  Cable Parameter

AWG (No of Strands/Strand Diameter)No. of Cores x Nominal Cross Sectional AreaNominal Thickness of InsulationNominal Overall DiameterNominal Copper WeightNominal Weight#xmm^2mmmmkg/kmkg/km181x10.60.84.527161x1.50.70.84.936141x2.50.80.85.85212(7/20)1x40.90.96.87610(7/18)1x60.80.97.41008(7/16)1x1010.98.81606(7/14)1x161110.52304(7/12)1x251.21.112.53402(7/10)1x351.21.113.54401(19/13)1x5011.413.75412/0(19/11)1x701.11.415.87493/0(19/10)1x951.11.517.510004/0(37/12)1x1201.21.519.31241300MCM(37/11)1x1501.41.621.51523350MCM(37/10)1x1851.61.624.71942500MCM(61/11)1x2401.71.727.72514-(61/10)1x3001.81.830.63125-(61/9)1x40021.934.23967-(61/8)1x5002.22385063-(127/10)1x6302.42.242.96491

Packing shipping





Please contact us for technical support with the right cable selection for your power distribution projects and to discuss your maintenance or project specific requirements. We provide tailored solutions for this cable range which include storage, cutting to length, and 2 days collection as standard.

Any problem and inquiry pls contact with Vivian Yuan
