600V Copper Aluminum XLPE Insulated PVC Covered Ser Electric Wire Cable
Henan Hongda Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Housing Use
- Conductor Material：Copper and Aluminum
- Sheath Material：PVC
- Insulation Material：XLPE
Base Info
- Model NO.：SER wire cable
- Material Shape：Round Wire
- Range of Application：Housing Use
- Certification：ISO9001, CCC
- Brand：Hongda
- Voltage：600V
- Standard：IEC UL
- Cable Type：Ser
- Transport Package：Roll and Pallet
- Specification：4AWG
- Trademark：HONGDA
- Origin：Henan,China
- HS Code：8544492100
- Production Capacity：10km,Day
Description
Size
AWG
MCM
Area
mm²
STRANDING
No. of wires
per diameter
in mm.
INSULATION
THICKNESS
mm
NEUTRAL.
No. of wires
per diameter
in mm.
JACKET
THICKN.
mm
OUTSIDE
DIAMETER.
mm
TOTAL
WEIGTH
Kg/Km
AMPACITY
For 1 cond.
in free air
Amp.
PACKAGING
3 x 8
8,34
1 x 3,26
1,14
---
1,52
14,22
175,00
45
A,Z
3 x 6
13,31
7 x 1,55
1,14
---
1,52
17,02
247,00
60
A,Z
3 x 4
21,15
7 x 1,96
1,14
---
2,03
20,53
328,00
75
A,Z
3 x 2
33,62
7 x 2,47
1,14
---
2,03
23,61
464,00
100
A,Z
3 x 1
42,36
19 x 1,68
1,40
---
2,03
26,66
581,00
115
A,Z
3 x 1/0
53,49
19 x 1,89
1,40
---
2,03
28,78
697,00
135
A,Z
3 x 2/0
67,43
19 x 2,12
1,40
---
2,03
31,10
839,00
150
A,Z
3 x 3/0
85,01
19 x 2,39
1,40
---
2,03
33,82
1016,00
175
A,Z
3 x 4/0
107,20
19 x 2,68
1,40
---
2,03
36,75
1235,00
205
A,Z
3x8 + 1x8
8,34
1 x 3,26
1,14
1 x 3,26
1,52
15,95
204,00
45
A,Z
3x6 + 1x6
13,31
7 x 1,55
1,14
7 x 1,55
2,03
20,21
290,00
60
A,Z
3x4 + 1x6
21,15
7 x 1,96
1,14
7 x 1,55
2,03
23,07
373,00
75
A,Z
3x2 + 1x4
33,62
7 x 2,47
1,14
7 x 1,96
2,03
26,64
532,00
100
A,Z
3x1 + 1x3
42,36
19 x 1,68
1,40
7 x 2,23
2,03
30,16
666,00
115
A,Z
3x1/0 + 1x2
53,49
19 x 1,89
1,40
7 x 2,47
2,03
32,60
802,00
135
A,Z
3x2/0 + 1x1
67,43
19 x 2,12
1,40
19 x 1,68
2,03
35,28
970,00
150
A,Z
3x3/0 + 1x1/0
85,01
19 x 2,39
1,40
19 x 1,89
2,03
38,43
1178,00
175
A,Z
3x4/0 + 1x2/0
107,20
19 x 2,68
1,40
19 x 2,12
2,03
41,81
1437,00
205
A,Z
4x2 + 1x4
33,62
7 x 2,47
1,14
7 x 1,96
2,03
29,30
671,00
100
A,Z
4x2/0 +1x1
67,43
19 x 2,12
1,40
19 x 1,68
2,03
38,97
1227,00
150
A,Z
4x4/0 + 1x2/0
107,20
19 x 2,68
1,40
19 x 2,12
2,79
47,78
1824,00
205
A,Z
company information:
Hongda cable Co., Ltd. is one of the most professional cable & wire producer under modern enterprise system in China, which was founded in 1988, integrating scientific research, development, production and sales. Henan Hongda Cable Co., is the original Zhengzhou Hongda Cable Co., The company mainly produces 1-35 kV power cable, TW, THW, THHW, THHN electrical wire, ABC cable, Overhead Cable, AAC, AAAC, ACSR, ACAR bare conductor, Concentric Cable, etc
Our advantages
1. With more than 17 years manufacturing experience, our products are strictly in accordance with ISO, SGS, CCC ;
2. Good cost-control system, with highly-competitive prices;
3. Strong and Professional R&D team to meet your specific needs;
4. Fast delivery&reliable products are always the reason why you choose us.
Custom Merchandise: we can make cable as your need include the color ,size and so on.we also offer OEM
