Copper Clad Aluminum Magnesium Wire
Hangzhou Spring Electronics Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, LAN Cable, Long Distance Symmetric Cable, RF Cable, Submarine Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：Non
- Type：Cat 1
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：ccam
- Wire Core Material：CCA
- Certification：CE, ISO, RoHS
- Model：Coaxial
- Brand：Fuu
- Transport Package：Carton
- Specification：305m,roll
- Trademark：FUU
- Origin：Made in China
- HS Code：8544200000
- Production Capacity：5000km,Month
Description
Basic Info.
Model NO. ccam Wire Core Material CCA Certification CE, ISO, RoHS Model Coaxial Brand Fuu Transport Package Carton Specification 305m/roll Trademark FUU Origin Made in China HS Code 8544200000 Production Capacity 5000km/MonthProduct Description
Copper Clad Aluminum Magnesium Wire
Copper clad aluminum wire is produced with the production process of cladding-welding- drawing method, by cladding planished copper stripe concentrically on the outer surface of the aluminium core, via several times of drawing and heat treatment, to meet customers' technical requirement on line diameter, mechanical property and electrical property. The copper clad aluminum wire characterizes by both the samll density of aluminum and the good conductivity of copper.Name
Spec. |
Diameter
| Copper In volume | Copper In mass | Conductivity | Tensile Strength | Elongation | Density |
CCAM-D
| 0.12 -3.00mm | Cu < 10 | Cu < 26.8
| ± 37% | ± 220 Mpa | ≥ 8 % |
2.9 -- 3.0 g/cm3
|
CCAM-10 | 0.12-3.00mm | Cu-10 % | Cu 26.8-30%
| 55% - 57% | ± 180 Mpa | ≥ 10 % | 3.62- 3.7 g/cm3
|
CCAM-15 | 0.12 -3.00mm | Cu-15% | Cu 37-40%
| 57% ---59% | ± 190 Mpa | ≥ 10 % | 3.72- 3.8 g/cm3
|
