• Model NO.：BV,BVR
• Material Shape：Round Wire
• Range of Application：Indoor
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE
• Brand：Dayuan
• Conductor：Annealed Copper Wire,Solid or Stranded
• Max.Operating Temperature：70,90,105 Degree
• Voltage：300,500V,450,750V
• Color：Black,Brown,Grey,Blue,Green,Yellow
• OEM/ODM：Ok
• Transport Package：Packed as Rolls, or Wooden Drum or as Customized
• Specification：IEC, ISO, GB, TUV, CCC
• Trademark：Da Yuan
• Origin：Henan, China
• HS Code：8544492100
• Production Capacity：100000 M,Day

Norminal Sectional area mm2Conductor No/Dia.mmNominal Insulated thick mmMax overall Dia.mmConductor Resistance at 20°CMin insulated resistance at 70MΩ/KMWeight Kg/kmCuAlCuAl1.51/1.380.7 3.3 12.1-0.011 19.2 -1.57/0.520.7 3.5 12.1-0.010 20.6 -2.51/1.780.8 3.9 7.4111.80.010 30.815.0 41/2.250.8 4.4 4.617.390.008545.521.0 61/2.760.8 4.9 3.084.910.0070 65.0 29.0 107/1.351.0 7.0 1.833.080.0065110.0 52.0 167/1.71.0 8.0 1.151.910.0050 170.0 70.0 257/2.141.2 10.0 0.7271.20 0.0050 270.0 110.0 357/2.521.2 11.5 0.5240.8680.0040 364.0 150.0 5019/1.781.4 13.0 0.3870.6410.00455000.0 200.0 7019/2.141.4 15.0 0.2680.4430.0035688.0 269.0 9519/2.521.6 17.5 0.1930.320 0.0035953.0 360.0 12037/2.031.6 19.0 0.1530.2530.00321168.0 449.0 15037/2.251.8 21.0 0.1240.2060.00321466.0 551.0 18537/2.522.0 32.5 0.0990.1640.00321808.0 668.0
 BV/BVR Cable data 2:

Norminal Sectional area mm2	Conductor No/Dia.mm	Nominal Insulated thick mm	Max overall Dia.mm	Conductor Resistance at 20°C	Min insulated resistance at 70MΩ/KM	Weight Kg/km
2.5	9/0.41	0.8	4.2	7.41	0.011	33.0
4	19/0.52	0.8	4.8	4.61	0.009	48.0
6	19/0.64	0.8	5.6	3.08	0.0084	68.0
10	49/0.64	1.0	7.6	1.83	0.0072	115.0
16	49/0.64	1.0	8.8	1.15	0.0062	176.0
25	98/0.58	1.2	11.0	0.727	0.0058	272.0
35	133/0.58	1.2	12.5	0.524	0.0052	384.0
50	133/0.68	1.4	16.5	0.387	0.0051	510.0
70	189/0.68	1.4	16.5	0.268	0.0045	714.0
95	259/0.68	1.0	19.5	0.139	0.0035	965.0
120	259/0.76	1.8	22.0	0.153	0.0032	1210.0

All the goods are full meter and  working life are 25 years!
Company Information
BV cable  factory and worshop corner
Our factory is about 200,081m2 with register capital about 200 million. 700 stuff and 40 engineer.  every step is to make sure the delivery time and quality!


Packaging & Shipping

BV cable  packing, we can also make it as your need for that  we have two professional wooden engineer.

Inspection machine

BV cable six inspection machine

We inspect every product before deliverying the goods to ensure the quality!
