Cat3 3 Pairs Twisted Unshielded Telephone Cable

Hangzhou Risun Cable Co., Ltd.

Application：Local Communication Cable, LAN Cable
Conductor Material：BC,CCS,CCA,TC,CU,CCAG
Cover Material：PVC
Type：Cat 3
Material Shape：Round Wire
Conductor Type：Stranded

Base Info

Model NO.：cat3
Wire Core Material：Bare Copper Wire
Certification：CE, ISO, RoHS, ETL SGS CPR
Brand：Risun or OEM
Insulation：HDPE
Jacket：PE,PVC,Lszh
Ripcord：500d,1000d
UV, Jelly, Fr：Available
Transport Package：100m,200m,300m,Roll
Specification：ETL, CE, ROHS, ISO9001
Trademark：RISUN or OEM
Origin：Hangzhou, China(Mainland)
HS Code：8544491100
Production Capacity：20000 Boxes , Month

Description

ElongationMin. 300%Temperature Range-20 up to +75° CTensile StrengthMin 1.68kg/mm²

Electrical Properties:

Conductor ResistanceMax. 9.38 ohm/100mResistance UnbalanceMax. 2%Insulation Resistance150 ohm/KMMutual CapacitanceMax. 5600pF/100mCapacitance UnbalanceMax. 330pF/100mImpedance100+/-15 ohmSpark Test2000VVelocity of Propagation67%

Technical Performance:

	Attenuation	RL	Next	PS Next
(MHZ)	(dB/100m)	(dB)	(dB)	(dB)
1MHZ	2.6	12	41.3	41.3
4MHZ	5.6	12	32.3	32.3
8MHZ	8.5	12	27.8	27.8
10MHZ	9.7	12	26.3	26.3
16MHZ	13.1	12	23.3	23.3
